ORBITAL HEAD GROUP (i20NBT-OB)
DIA
NO.
PART
NUMBER
DESCRIPTION
NO
REQ'D
1
8146199 MOTOR, 24VDC 550W 2200RPM, KIT 1
8146198 CARBON BRUSH, MOTOR 2
2 8146110 KEY, 8×7×28 1
3 1123012 LOCK NUT, M10 16
4 1421030 FLAT WASHER M10×
∮
30×2.5 24
5 8146520 MOUNTING BRACKET, ORBITAL HEAD 2
6 8146116 ISOLATORS, M10×25 6
7 8146501 BRACKET, MOTOR MOUNTING 1
8 1022845 HEX BOLT M8×45 2
9 1421824 FLAT WASHER M8×
∮
24×2.0 6
10 8115404 BEARING, JOURNAL 4
11 1435013 WAVE WASHER 2
12 8116009 PROTECTIVE WHEEL 2
13 1123810 LOCK NUT, M8 2
14 1221515 SCREW M5×15 4
15 1421510 FLAT WASHER M5×
∮
10×1.0 8
16 8146303 END CAP 3/8 2
17 8146305 PLASTIC CLAMP 4
18 8146508 PVC TUBING 2
19 8146301 TEE FITTING 3/8 1
20 1123507 LOCK NUT M5 4
21 1513616 HEX SOCKET SCREW, M6×16 4
22 8146202 ECCENTRIC 1
23 8146201 ECCENTRIC SHAFT 1
24 1535610 SET SCREW, M6×10 1
25 8146204 BEARING HOUSING 1
26 1612608 BALL BEAING 6008 1
27 8146203 BEARING HOUSING 1
28 1521616 HEX SOCKET BOLT M6×16 2
29 8146107 ISOLATORS, M10×25 4
30 8146502 PAD DRIVER 1
31 1513020 HEX SOCKET SCREW, M10×20 4
32 1513625 HEX SOCKET SCREW, M6×25 4
33 8146205 PLATE 1
34 1513620 HEX SOCKET SCREW, M6×20 4
35 8146511 ELBOW, 3/8 1
36 8146512 TUBING, WIRE REINFORCED 1
