Ice iE410 User Manual

ICE iE410
9
OPERATOR
PARTS LIST
DIA
NO
PART
NUMBER
DESCRIPTION
NO
REQ'D
1 2320216 Clear Dome 1
2 2320218 Gasket,Clear Dome 1
3 2320217 Rubber Hinge 1
4 1421409 Washer,Plain,
Φ
4.3X
Φ
9X0.8 4
5 1321210 Screw, Ph, St4 X10 4
6 1221410 Screw, Ph, M4 X10 2
7 6210109 Bend, Tube 1
8 6210104 Coupler 1
9 6210103 Gasket,Coupler 1
10 6210108 Elbow 1
11 6210114 Coupler,Vac Hose 1
12 2230131 Plug, Serial number:000000-001234
1
13
6210705 Drain Hose, Serial number:000000-001234 1
8011030 Drain Hose,Serial number:001235- 1
14 6210113 Vac Hose 1
15 1962050 Clamp, Hose 2" 1
16 1021610 Screw, Hex, M6X10,SST 1
17 1422616 Washer, Lock, SST, Ø6 1
18 1421617 Washer, Plain,
Φ
6X
Φ
16X2 1
19 6150712 Clamp, Cord 1
20 6210503 Rocker Switch 1
21 6210502 Push Button Switch 1
22 6210504 Circuit Breaker, 2A 1
23 1221512 Screw, M5X12, PH 3
24 6210111 Clamp, Drain Hose 1
25 6210125 Warning Decal 1
26 6210501 Switch Housing 1
27 4020310 Strain Relief 1
28 6210518 Power Cord 1
29 6210505 Elbow Corrugated Tubing Fitting 1
30 6210506 Corrugated Tubing 1
31 6210136 Barb, Right Angle 1
32 6210135 Tubing 1
33 6180163 Barb, Hose 1
34 6180126 Nut, Coupling 1
35 6120667 Washer, Lock, Internal Toooth 1
36 6160509 Gasket, Solution, Intake 2
37 6120276 Washer, Plain 1
38 6180125 Coupling 1
39 6110411 Strainer, Line 1

Ice iE410 Specifications

General

Brand	Ice
Model	iE410
Category	Floor Machine
Language	English
