MANUAL for KG30 - KG50 SUpreMe
DRY ICE BLASTING EQUIPMENT FROM ICETECH | PAGE 9
“ The blasting gun is ergonomically
designed. The gun is built up of modules and
can be adapted to suit any task. ”
ICEGUN HD SUPREME WITH LIGHT
1 Light.
2 Safety switch.
3 Two-step trigger.
- Blasting with dry ice AND air.
- Blasting with AIR ONLY.
4 Signal cable.
5 Standard Round Nozzle
- interchangeable.
6 Nozzle holder.
Dim. (mm/inch)
– incl. nozzle and nozzle holder
Length: 320 / 12.5
Width: 60 / 2.36
Height: 185 / 7.28
Weight
– incl. nozzle and nozzle holder
g: 1150 / lbs: 2.53
Light max 20 min without blasting
Fault Cause Remedy
Only air is coming out of the
gun
No signal to IceGun
Trigger on gun is not fully
depressed
Connection lost in blast hose
IceGun has a two-step trigger,
half depressed blast air only
Call technician to be further
diagnosed
3
2
5
4
6
1
