MANUAL for KG30 - KG50 SUpreMe
DRY ICE BLASTING EQUIPMENT FROM ICETECH | PAGE 15
Nozzle Diameter and Blast Pattern
Thenozzleselectionshouldbebasedonnding
the best combination of air consumption, dry ice
consumptionandcleaningefciency.
The selection of the nozzle spread angle should
depend on how strong or weak a cleaning effect is
desired for a given dry ice consumption.
Small Blast Pattern
A small blast pattern gives a concentrated jet with a
high cleaning effect on a small area.
Wide Blast Pattern
Alargespreadangle,e.g.theatnozzle,resultsin
a jet which for the same consumption of dry ice and
air cleans a larger area with a lesser cleaning effect.
Nozzle Size
It is most important to select the size of nozzle
which will provide the desired air velocity using
the available compressor capacity. Choosing the
right nozzle size and type will optimize not only the
cleaning effect, but also the dry ice consumption
and the time required for the cleaning process itself.
Refer to the air consumption table for guidance on
the nozzle selection.
Air Consumption Table
The air consumption table indicates the air con-
sumption in relation to nozzle size and blasting
pressure. The maximum supply pressure of KG50
and KG30 amounts to 16 bar/232 psi.
Example of Use of the Table
The air consumption table outlines the air consump-
tion achieved with the nozzle sizes available. If for
example a size 8 nozzle is used at a blasting pres-
sure of 6 bar (87 psi) the air consumption amounts
to 4.2 Nm
3
/min (148.3 ft
3
/min).
The available compressor capacity will always need
to be taken into consideration and therefore it may
be necessary to do some test blasts and observe
the results until the optimum combination of nozzle
size and blasting pressure for a certain application
is found.
NOZZLE SELECTION AND AIR CONSUMPTION
KG 6/20
KG 12
KG 30
KG 50
Air consumption in Nm
3
/min - ft
3
/min
at the pressures indicated (bar/psi)
Ø = nozzle diameter
KG 6/20
KG 12
KG 30
KG 50
AIR CONSUMPTION TABLE
Bar» 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Ø 5 0.7 0.9 1.2 1.4 1.6 1.9 2.1 2.3 2.6 2.8 3.0 3.3 3.5 3.7 4.0
Ø 6 1.0 1.3 1.7 2.0 2.4 2.7 3.0 3.4 3.7 4.0 4.4 4.7 5.1 5.4 5.7
Ø 7 1.4 1.8 2.3 2.7 3.2 3.7 4.1 4.7 5.1 5.7 6.2 6.6 7.1 7.4 7.7
Ø 8 1.8 2.4 3.0 3.6 4.2 4.8 5.4 6.1 6.7 7.3 7.9 8.4 9.1 9.7 10
Ø 9 2.3 3.0 3.8 4.6 5.3 6.1 6.9 7.7 8.4 9.4 10.1 10.8 11.7 12.1 13
Ø 10 2.8 3.7 4.7 5.7 6.6 7.6 8.5 9.6 10.4 11.3 12.4 13.4 14.3 15.3 16
AIR CONSUMPTION TABLE
psi» 29 44 58 73 87 102 116 131 145 160 174 189 203 218 232
Ø 5 25 32 42 49 56 67 74 81 92 99 106 116 124 131 141
Ø 6 35 46 60 71 85 95 106 120 131 141 155 166 180 191 201
Ø 7 49 64 81 95 113 131 145 166 180 201 219 233 251 261 272
Ø 8 64 85 106 127 148 169 191 215 237 258 279 297 321 342 353
Ø 9 81 106 134 162 187 215 244 272 297 332 357 381 413 427 459
Ø 10 99 131 166 201 233 268 300 339 367 399 438 473 505 540 565
Air consumption in m
3
free air/min
Air consumption in ft
3
/min
