Icom AT-140 Service Manual

[TUNER UNIT]
R14 7010003950 RESISTOR R20J 10 Ω T
R15 7010004320 RESISTOR R20J 10 kΩ T
R16 7070000730 RESISTOR CRH200 R-02J 330 Ω T
R17 7070000731 RESISTOR ERG2SJ 331 (330 Ω)T
R18 7070000721 RESISTOR ERG2SJ 271 (270 Ω)T
R19 7070000291 RESISTOR ERG2SJ 221 (220 Ω)T
R20 7070000291 RESISTOR ERG2SJ 221 (220 Ω)T
R21 7070000291 RESISTOR ERG2SJ 221 (220 Ω)T
R22 7070000301 RESISTOR ERG1SJ 331 (330 Ω)T
R23 7070000301 RESISTOR ERG1SJ 331 (330 Ω) T
R24 7070000711 RESISTOR ERG1SJ 271 (270 Ω) T
R25 7010004410 RESISTOR R20J 47 kΩ T
R26 7010004410 RESISTOR R20J 47 kΩ T
R27 7010003440 RESISTOR ELR20J 2.2 kΩ T
R28 7010004690 RESISTOR R50XJ 47 Ω T
R29 7010004690 RESISTOR R50XJ 47 Ω T
R30 7010004690 RESISTOR R50XJ 47 Ω T
R31 7010004690 RESISTOR R50XJ 47 Ω T
R32 7010004030 RESISTOR R20J 47 Ω T
R33 7010004490 RESISTOR R20J 220 kΩ T
R34 7010004490 RESISTOR R20J 220 kΩ T
R35 7010004420 RESISTOR R20J 56 kΩ T
R36 7010004230 RESISTOR R20J 2.2 kΩ T
R37 7010004410 RESISTOR R20J 47 kΩ T
R38 7010004190 RESISTOR R20J 1 kΩ T
R39 7010004320 RESISTOR R20J 10 kΩ T
R40 7010004320 RESISTOR R20J 10 kΩ T
R41 7010004320 RESISTOR R20J 10 kΩ T
R42 7010003400 RESISTOR ELR20J 1 kΩ T
R43 7010001020 RESISTOR R25XJ 82 Ω T
R44 7010004110 RESISTOR R20J 220 Ω T
R45 7540000010 ABSORBER DSA-301LA T
R46 7010000590 RESISTOR ELR25J 47 kΩ T
R47 7010003200 RESISTOR ELR20J 22 Ω T
R49 7010000160 RESISTOR ELR25J 18 Ω T
R51 7010004940 RESISTOR ELR25J 68 Ω T
R52 7010001010 RESISTOR R25XJ 68 Ω T
R53 7010004400 RESISTOR R20J 39 kΩ T
R54 7010003380 RESISTOR ELR20J 680 Ω T
R55 7100000150 RESISTOR SRW2P 22 Ω (220) T
R56 7010003580 RESISTOR ELR20J 22 kΩ T
R57 7010004450 RESISTOR R20J 100 kΩ T
R58 7010004250 RESISTOR R20J 3.3 kΩ T
R59 7010003550 RESISTOR ELR20J 15 kΩ T
R60 7010004230 RESISTOR R20J 2.2 kΩ T
R61 7010003490 RESISTOR ELR20J 5.6 kΩ T
R62 7010004110 RESISTOR R20J 220 Ω T
R63 7010003390 RESISTOR ELR20J 820 Ω T
R64 7010003620 RESISTOR ELR20J 47 kΩ T
R66 7010003660 RESISTOR ELR20J 100 kΩ T
R67 7010004410 RESISTOR R20J 47 kΩ T
R68 7080001191 RESISTOR RN14K2E 390 kΩ T
R70 7410000082 ARRAY RGLD4X473J T
R71 7010003400 RESISTOR ELR20J 1 kΩ T
R72 7010004190 RESISTOR R20J 1 kΩ T
R73 7010004190 RESISTOR R20J 1 kΩ T
R74 7010004190 RESISTOR R20J 1 kΩ T
R75 7010003320 RESISTOR ELR20J 220 Ω T
R76 7010003660 RESISTOR ELR20J 100 kΩ T
R77 7010003700 RESISTOR ELR20J 220 kΩ T
R78 7080000411 RESISTOR RN14K2E 480 kΩ T
R79 7410000222 ARRAY RGLD8X473J T
R80 7410000222 ARRAY RGLD8X473J T
R81 7410000222 ARRAY RGLD8X473J T
R82 7010003620 RESISTOR ELR20J 47 kΩ T
R83 7410000202 ARRAY RGLD8X222J T
R84 7010004150 RESISTOR R20J 470 Ω T
R85 7010004150 RESISTOR R20J 470 Ω T
R86 7010004150 RESISTOR R20J 470 Ω T
R87 7010004150 RESISTOR R20J 470 Ω T
R88 7010004150 RESISTOR R20J 470 Ω T
R89 7010004150 RESISTOR R20J 470 Ω T
R90 7010004150 RESISTOR R20J 470 Ω T
R91 7410000202 ARRAY RGLD8X222J T
R92 7010004150 RESISTOR R20J 470 Ω T
R93 7010004150 RESISTOR R20J 470 Ω T
R94 7010004150 RESISTOR R20J 470 Ω T
R95 7010004150 RESISTOR R20J 470 Ω T
R96 7010004150 RESISTOR R20J 470 Ω T
R97 7010004150 RESISTOR R20J 470 Ω T
R98 7010004150 RESISTOR R20J 470 Ω T
R99 7010004150 RESISTOR R20J 470 Ω T
R100 7410000202 ARRAY RGLD8X222J T
R101 7010004150 RESISTOR R20J 470 Ω T
R102 7010004150 RESISTOR R20J 470 Ω T
R103 7010004150 RESISTOR R20J 470 Ω T
R104 7010004150 RESISTOR R20J 470 Ω T
R105 7010004150 RESISTOR R20J 470 Ω T
S.=Surface mount
5 - 2
REF ORDER
DESCRIPTION M.
NO. NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[TUNER UNIT]
R106 7010004150 RESISTOR R20J 470 Ω T
R107 7010004150 RESISTOR R20J 470 Ω T
R108 7010004150 RESISTOR R20J 470 Ω T
R109 7010003990 RESISTOR R20J 22 Ω T
R111 7010003990 RESISTOR R20J 22 Ω T
R113 7010003990 RESISTOR R20J 22 Ω T
R115 7010003990 RESISTOR R20J 22 Ω T
R117 7010003990 RESISTOR R20J 22 Ω T
R119 7010003990 RESISTOR R20J 22 Ω T
R121 7010003990 RESISTOR R20J 22 Ω T
R123 7010003990 RESISTOR R20J 22 Ω T
R125 7010003990 RESISTOR R20J 22 Ω T
R127 7010003990 RESISTOR R20J 22 Ω T
R129 7010003990 RESISTOR R20J 22 Ω T
R131 7010003990 RESISTOR R20J 22 Ω T
R133 7010003200 RESISTOR ELR20J 22 Ω T
R135 7010003990 RESISTOR R20J 22 Ω T
R137 7010003990 RESISTOR R20J 22 Ω T
R139 7010003990 RESISTOR R20J 22 Ω T
R141 7010003990 RESISTOR R20J 22 Ω T
R143 7010003990 RESISTOR R20J 22 Ω T
R145 7010003990 RESISTOR R20J 22 Ω T
R147 7010003990 RESISTOR R20J 22 Ω T
R149 7010004150 RESISTOR R20J 470 Ω T
R150 7010003480 RESISTOR ELR20J 4.7 kΩ T
R151 7010003440 RESISTOR ELR20J 2.2 kΩ T
R152 7010000940 RESISTOR R25XJ 18 Ω T
R154 7010000940 RESISTOR R25XJ 18 Ω T
R156 7010003620 RESISTOR ELR20J 47 kΩ T
R157 7080001191 RESISTOR RN14K2E 390 kΩ T
R158 7010003450 RESISTOR ELR20J 2.7 kΩ T
R159 7010003530 RESISTOR ELR20J 10 kΩ T
R160 7010003360 RESISTOR ELR20J 470 Ω T
R161 7010003620 RESISTOR ELR20J 47 kΩ T
R162 7010003620 RESISTOR ELR20J 47 kΩ T
R163 7010004450 RESISTOR R20J 100 kΩ T
R164 7010004450 RESISTOR R20J 100 kΩ T
R165 7010000940 RESISTOR R25XJ 18 Ω T
R167 7010003410 RESISTOR ELR20J 1.2 kΩ T
R168 7010003410 RESISTOR ELR20J 1.2 kΩ T
R169 7010003410 RESISTOR ELR20J 1.2 kΩ T
R170 7010003410 RESISTOR ELR20J 1.2 kΩ T
R171 7010003410 RESISTOR ELR20J 1.2 kΩ T
R172 7010003410 RESISTOR ELR20J 1.2 kΩ T
R173 7010003410 RESISTOR ELR20J 1.2 kΩ T
R174 7010003410 RESISTOR ELR20J 1.2 kΩ T
R175 7010003410 RESISTOR ELR20J 1.2 kΩ T
R176 7010003410 RESISTOR ELR20J 1.2 kΩ T
R177 7010003410 RESISTOR ELR20J 1.2 kΩ T
R178 7010003410 RESISTOR ELR20J 1.2 kΩ T
R179 7010003410 RESISTOR ELR20J 1.2 kΩ T
R180 7010003410 RESISTOR ELR20J 1.2 kΩ T
R181 7010003410 RESISTOR ELR20J 1.2 kΩ T
R182 7010003410 RESISTOR ELR20J 1.2 kΩ T
R183 7010003410 RESISTOR ELR20J 1.2 kΩ T
R184 7010003410 RESISTOR ELR20J 1.2 kΩ T
R185 7010003410 RESISTOR ELR20J 1.2 kΩ T
R186 7010003410 RESISTOR ELR20J 1.2 kΩ T
R187 7010003410 RESISTOR ELR20J 1.2 kΩ T
R188 7010003410 RESISTOR ELR20J 1.2 kΩ T
R189 7010003410 RESISTOR ELR20J 1.2 kΩ T
R190 7010001030 RESISTOR R25XJ 100 Ω T
R191 7010001190 RESISTOR R25XJ 2.2 kΩ T
R192 7010003520 RESISTOR ELR20J 8.2 kΩ T
R193 7010003720 RESISTOR ELR20J 330 kΩ T
R194 7310000660 TRIMMER RH0621C14J19A (103) T
R195 7010003400 RESISTOR ELR20J 1 kΩ T
R196 7010003490 RESISTOR ELR20J 5.6 kΩ T
R197 7010005210 RESISTOR R20J 10 MΩ T
R198 7010004420 RESISTOR R20J 56 kΩ T
R200 7010003660 RESISTOR ELR20J 100 kΩ T
R201 7010004190 RESISTOR R20J 1 kΩ T
R202 7010003700 RESISTOR ELR20J 220 kΩ T
R203 7010003620 RESISTOR ELR20J 47 kΩ T
R204 7010004410 RESISTOR R20J 47 kΩ T
R205 7410000352 ARRAY RGLD3X104J T
R206 7410000352 ARRAY RGLD3X104J T
R207 7410000352 ARRAY RGLD3X104J T
R208 7410000352 ARRAY RGLD3X104J T
R209 7410000352 ARRAY RGLD3X104J T
C1 4020000990 CYLINDER UP050 B 473K-NA-CZ T
C2 4010005610 CERAMIC HM60SJ SL 100D 500V T
C3 4010000380 CERAMIC DD106-601 SL 221J 50V T
C4 4010000410 CERAMIC DD107 SL 331J 50V T
C5 4020000990 CYLINDER UP050 B 473K-NA-CZ T
C6 4010005660 CERAMIC HM60SJ SL 220J 500V T
REF ORDER
DESCRIPTION M.
NO. NO.

Icom AT-140 Specifications

General

Compatibility	IC-M802
Product color	Gray
Frequency range	1.6 - 30 MHz
Brand compatibility	ICOM
Quantity	1
