SECTION 6 MECHANICAL PARTS
6 - 1
W501 8900011380 Cable OPC-1146 [AT-140] only 1
W502 8900011400 Cable OPC-1164 [AT-140] only 1
EP501 6910000880 Sheet NC-1 (SUS) [AT-130/E] only 1
EP502 6910000880 Sheet NC-1 (SUS) [AT-130/E] only 1
MP501 8310006540 High voltage waring seal 1
MP502 8010003411 Case (A)-1 [USA][EUR][USA-2] 1
8010016911 Case (I)-1 [USA-1][EUR-1] 1
8010019030 1157 U-case [AT-140] 1
MP503 8010003331 Case (B)-1 [USA][EUR][USA-2] 1
8010016921 Case (J)-1 [USA-1][EUR-1] 1
8010019020 1157 L-case [AT-140] 1
MP504 8930006900 Mounting plate 2
MP505 8930006540 Waterproof seal 1
MP506 8930002800 O ring (G) 2
MP507 8930006550 Sealing washer (A) [AT-130/E] only 1
MP508 8930006560 Sealing washer (C) 1
MP509 8930006570 Sealing washer (D) 4
MP510 6910000470 Pair insulator 1
MP512 8310027360 1157 caution seal (P) [AT-130] only 1
8310053950 Caution seal (P) [AT-140] only 1
MP517 8810000620 Screw PH M3 × 13 SUS [AT-130/E] only 1
MP518 8830000230 Nut M3 SUS [AT-130/E] only 1
MP519 8810003480 Hexagon bolt M5 × 60 SUS 1
MP520 8860000160 Earth lug B8 (M5) AG BS 1
MP521 8850000500 Spring washer M5 SUS 1
MP522 8850000180 Flat washer M5 SUS 1
MP523 8830000250 Nut M5 SUS 1
MP524 8860000190 Earth lug (M5) AG BS 1
MP525 8850000600 Gear Washer M5 SUS 1
MP526 8830000370 Wing nut M5 SUS 1
MP527 8810003470 Hexagon bolt M5 × 20 SUS 1
MP528 8860000160 Earth lug B8 (M5) AG BS 1
MP529 8850000500 Spring washer M5 SUS 1
MP530 8850000180 Flat washer M5 SUS 1
MP531 8830000250 Nut M5 SUS 1
MP532 8860000190 Earth lug D5 (M5) AG BS 1
MP533 8850000600 Gear Washer M5 SUS 1
MP534 8830000370 Wing nut M5 SUS 1
MP535 8810002800 Screw trass head M5 × 10 SUS 4
MP536 8810000660 Screw PH M4 × 14 SUS 10
MP537 8810001480 Screw PH A M5 × 10 SUS 2
MP538 8810001690 Screw PH B0 3 × 8 (PL) [AT-130E] 6
8810001690 Screw PH B0 3 × 8 (PL) [AT-130/140] 9
MP539 8830000240 Nut M4 SUS 10
MP541 8930006570 Sealing washer (D) 1
MP544 8930006570 Sealing washer (D) 1
MP545 8930006550 Sealing washer (A) [AT-130/E] only 1
MP546 8810000620 Screw PH M3 × 16 SUS [AT-130/E] only 1
MP547 8830000230 Nut M3 SUS [AT-130/E] only 1
MP548 8930010360 Spacer D=4 L=28 T=0.6 [AT-130E] only 3
MP549 8810004260 Screw PH B1 M3 × 40 [AT-130E] only 3
MP550 8850000130 Flat washer M3 NI BS [AT-130E] only 3
MP551 8950001980 Cable tie-140 [AT-140] only 1
MP552 6910014570 Super ground (FGA13-08B) [AT-140] only 1
MP553 6910014570 Super ground (FGA13-08B) [AT-140] only 1
[CHASSIS PARTS]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
MP1 8930006910 Connector angle [AT-130/E] only 1
MP2 8510000821 RF case (B)-1 1
MP3 8510000840 RF case (B) upper cover 1
MP4 8510001081 Shield case (A)-1 1
MP5 8510001101 Shied case (A) cover (A)-1 1
MP6 8510004810 545 shield case 1
MP7 8510002020 MIX shield case 1
MP8 8410000100 DR heatsink 1
MP9 8810003170 Setscrew A M3 × 8 [AT-130/E] only 2
MP10 8810003160 Setscrew A M3 × 6 [AT-130/E] only 2
MP11 8810003180 Setscrew A M3 × 10 1
MP12 8830000190 Nut M3 NI BS 1
MP13 8510003350 RF case (B) lower case (A) 1
MP16 8860000130 Earth lug B5 (M3) AG BS [AT-130/E] only 1
MP17 8860000130 Earth lug B5 (M3) AG BS [AT-130E] only 1
MP18 8930000230 Stat (S) [AT-130E] only 1
MP19 8830000190 Nut M3 NI BS [AT-130E] only 1
MP20 8930017190 Earth spring (F) [USA-1][EUR-1] only 2
MP21 8810003290 Setscrew B M3 × 6 [AT-130E] only 1
MP22 8930004041 TR terminal-1 [AT-140] only 1
MP23 8930004041 TR terminal-1 [AT-140] only 1
[TUNER UNIT]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
W701 8900004200 Cable OPC-412 1
MP701 8820000440 U-bolt A SUS 2
MP702 8010000010 U-bolt plate 2
MP703 8830000260 Nut M6 SUS 4
MP704 8850000510 Spring washer M6 SUS 4
MP705 8850000190 Flat washer M6 SUS 4
MP706 8810001500 Screw PH A M6 × 30 SUS 4
MP707 8810003500 Hexagon bolt M6 × 50 SUS 4
MP708 8850000200 Flat washer M6 SUS 8
MP709 8830000260 Nut M6 SUS 4
MP710 8850000510 Spring washer M6 SUS 4
MP711 6950000010 Waterproof cap 1
[ACCESSORIES]
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
Screw abbreviations A,B0,B1: Self-tapping
PH: Pan head BS: Brass
NI: Nickel SUS: Stainless
