INTRODUCTION
This service manual describes the latest service information
for the
HM-151 HAND MICROPHONE,
at the time of
publication.
ORDERING PARTS
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit Icom part number
2. Component name and informations
3. Equipment model name and unit name
4. Quantity required
<SAMPLE ORDER>
8810009610 Screw FH M2.6 × 6 ZK HM-151
Top cover
10 pieces
Addresses are provided on the inside back cover for your
convenience.
To upgrade quality, all electrical or mechanical parts and internal
circuits are subject to change without notice or obligation.
MODEL NAME VERSION
HM-151
[GEN]
[GEN-02]
[GEN-01]
[EXP]
1. Make sure the problem is internal before disassembling
the speaker microphone.
2. DO NOT open the speaker microphone until the
transceiver is disconnected from its power source.
3. DO NOT force any of the variable components. Turn
them slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An
insulated tuning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the
speaker microphone is defective.
