Icom IC-2800 Service Manual

R240 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R241 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R242 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R243 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R244 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R245 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R246 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R247 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R248 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R249 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R250 7030003800 S.RESISTOR ERJ3GEYJ 105 V (1 MΩ)
R254 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R255 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R256 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R257 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R258 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R259 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R260 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R261 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R262 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R263 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R264 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R265 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R266 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R267 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R268 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R269 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R270 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R271 7030003290 S.RESISTOR ERJ3GEYJ 560 V (56 Ω)
R272 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R273 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R274 7030001200 S.RESISTOR MCR50JZHJ 390 Ω (391)
R275 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R276 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R277 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R278 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R279 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R280 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R281 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R282 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R283 7030003510 S.RESISTOR ERJ3GEYJ 392 V (3.9 kΩ)
[EUR], [ITA]
7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ) other
R284 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R285 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R286 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R287 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R288 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R289 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R290 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R291 7030003240 S.RESISTOR ERJ3GEYJ 220 V (22 Ω)
R292 7030005430 S.RESISTOR ERJ3GEYJ 3R3 V (3.3 Ω)
R293 7030000100 S.RESISTOR MCR10EZHJ 4.7 Ω (4R7)
R294 7030003490 S.RESISTOR ERJ3GEYJ 272 V (2.7 kΩ)
R295 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R296 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R297 7030003420 S.RESISTOR ERJ3GEYJ 681 V (680 Ω)
R298 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R299 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R300 7030003460 S.RESISTOR ERJ3GEYJ 152 V (1.5 kΩ)
R301 7030000130 S.RESISTOR MCR10EZHJ 8.2 Ω (8R2)
R302 7030000130 S.RESISTOR MCR10EZHJ 8.2 Ω (8R2)
C1 4510006650 S.ELECTROLYTIC ECEV 1EA 100SR
C2 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C3 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C4 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C5 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C6 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C7 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C8 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C9 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C10 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C11 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C12 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C13 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C14 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C15 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C16 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C17 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C18 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
[CONTROL UNIT]
R127 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R128 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R129 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R130 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R131 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R132 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R133 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R134 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R135 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R136 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R137 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R140 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R141 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R142 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R143 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R145 7210003020 VARIABLE EVU-F2KFK1 B14 (10KB)
R146 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R148 7210003020 VARIABLE EVU-F2KFK1 B14 (10KB)
R149 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R151 7210003020 VARIABLE EVU-F2KFK1 B14 (10KB)
R152 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R154 7210003020 VARIABLE EVU-F2KFK1 B14 (10KB)
R155 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R157 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R158 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R159 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R160 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R161 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R162 7030003520 S.RESISTOR ERJ3GEYJ 472 V (4.7 kΩ)
R163 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R164 7030003340 S.RESISTOR ERJ3GEYJ 151 V (150 Ω)
R165 7030003550 S.RESISTOR ERJ3GEYJ 822 V (8.2 kΩ)
R167 7030003650 S.RESISTOR ERJ3GEYJ 563 V (56 kΩ)
R168 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R169 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R170 7030003630 S.RESISTOR ERJ3GEYJ 393 V (39 kΩ)
R173 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R174 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
R175 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R176 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R177 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R178 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R179 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R180 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R181 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R182 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R183 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R184 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R185 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R186 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R187 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R188 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R189 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R190 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R191 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R192 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R193 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R194 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R195 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R196 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R197 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R198 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R199 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R200 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R201 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R202 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R203 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R204 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R205 7030003720 S.RESISTOR ERJ3GEYJ 224 V (220 kΩ)
R206 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R208 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R215 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R217 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R220 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R231 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R232 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R233 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R235 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R236 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R237 7030003390 S.RESISTOR ERJ3GEYJ 391 V (390 Ω)
R238 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R239 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
6 - 2
S.=Surface mount
REF ORDER
DESCRIPTION
NO. NO.
[CONTROL UNIT]
REF ORDER
DESCRIPTION
NO. NO.
