Icom IC-2800 Service Manual

REF ORDER
DESCRIPTION
NO. NO.
C121 4310001070 MYLAR 100 SMC 333K
C122 4030014540 S.CERAMIC GHM1038 SL 330J 3KV
C123 4510006970 S.ELECTROLYTIC ECEV1CA330WR
C124 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C125 4510006230 S.ELECTROLYTIC ECEV1EA470UP
C126 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C127 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C128 4510006970 S.ELECTROLYTIC ECEV1CA330WR
C129 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C130 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C131 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C132 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C133 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C134 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C135 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C136 4030007150 S.CERAMIC C1608 CH 1H 151J-T-A
C137 4030007150 S.CERAMIC C1608 CH 1H 151J-T-A
C138 4030007150 S.CERAMIC C1608 CH 1H 151J-T-A
C141 4030012600 S.CERAMIC C2012 JB 1A 105M-T-A
C142 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C143 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C144 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
C145 4030006940 S.CERAMIC C1608 CH 1H 030C-T-A
C146 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C147 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C148 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C149 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C150 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C151 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C152 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C153 4030007020 S.CERAMIC C1608 CH 1H 120J-T-A
[EUR], [ITA]
4030007040 S.CERAMIC C1608 CH 1H 180J-T-A other
C154 4030007130 S.CERAMIC C1608 CH 1H 101J-T-A
[EUR], [ITA]
4030007160 S.CERAMIC C1608 CH 1H 181J-T-A other
C155 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C156 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C157 4030009660 S.CERAMIC C1608 JF 1C 224Z-T-A
C158 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C159 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C160 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C164 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C165 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C166 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C167 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C168 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C169 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C172 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C173 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C174 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C175 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C176 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C177 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C178 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C179 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C181 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C183 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C184 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C185 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C186 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C187 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C188 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C189 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C190 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C191 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C192 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C193 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C194 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C195 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C196 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C197 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C199 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C200 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C201 4030009590 S.CERAMIC C2012 JF 1C 225Z-T-A
J1 6510017980 S.CONNECTOR IL-FPR-24S-HF-E3000
J2 6510021420 CONNECTOR 52018-6645
J3 6510003400 CONNECTOR B04B-EH-S
J4 6450001990 CONNECTOR JPJ2545-01-540
J5 6510014960 S.CONNECTOR B2B-ZR-SM3-TF
S.=Surface mount
C19 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C20 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C21 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C22 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C23 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C24 4030007140 S.CERAMIC C1608 CH 1H 121J-T-A
C25 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C26 4030010040 S.CERAMIC C1608 JB 1H 561K-T-A
C27 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C28 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C29 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C30 4030007080 S.CERAMIC C1608 CH 1H 390J-T-A
C31 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C33 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C34 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C35 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C36 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C37 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C38 4510006230 S.ELECTROLYTIC ECEV1EA470UP
C39 4510006970 S.ELECTROLYTIC ECEV1CA330WR
C40 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C41 4030008680 S.CERAMIC C2012 JF 1C 105Z-T-A
C44 4510004650 S.ELECTROLYTIC ECEV1EA4R7SR
C45 4030012660 S.CERAMIC C1608 JB 1C 683K-T-N
[EUR], [ITA]
4030006900 S.CERAMIC C1608 JB 1E 103K-T-A other
C52 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C53 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C54 4510004650 S.ELECTROLYTIC ECEV1EA4R7SR
C55 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C56 4030011280 S.CERAMIC C1608 CH 1H 271J-T-A
C57 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C58 4030011600 S.CERAMIC C1608 JB 1C 104KT-N
C59 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C67 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C70 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C71 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C72 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C73 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C74 4510006650 S.ELECTROLYTIC ECEV 1EA 100SR
C75 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C76 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C77 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C78 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C79 4030007170 S.CERAMIC C1608 CH 1H 221J-T-A
C80 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C81 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C82 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C83 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C84 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C85 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C86 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C87 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C89 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C90 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C91 4030008630 S.CERAMIC C1608 JF 1C 104Z-T-A
C92 4030006850 S.CERAMIC C1608 JB 1H 471K-T-A
C94 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C95 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C96 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C97 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C98 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C99 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C101 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C102 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C103 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C104 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C105 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C107 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C108 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C109 4030006880 S.CERAMIC C1608 JB 1H 472K-T-A
C110 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C111 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C112 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C113 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C114 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C115 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C116 4030006860 S.CERAMIC C1608 JB 1H 102K-T-A
C117 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C118 4030007090 S.CERAMIC C1608 CH 1H 470J-T-A
C119 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
C120 4030006900 S.CERAMIC C1608 JB 1E 103K-T-A
6 - 3
REF ORDER
DESCRIPTION
NO. NO.
[CONTROL UNIT] [CONTROL UNIT]
