Icom IC-7200 Installation Guide

19
FOR YOUR REFERENCE (Continued)
Specifications
Connector type USB B type
Interface USB 2.0/1.1
Power supply Self power The PC cannot recognize the transceiver when the power is OFF.
Support OS Windows Vista
Windows XP
Windows 2000
Serial for CI-V Compliant for CI-V spec.
Asynchronous serial
Construction (1 bite)
Start bit : 1
Data bit : 8
Parity bit : No
Stop bit : 1
Speed : 300/1200/4800/9600/19200 bps
Received audio output Number of data bit : 16-bit
Sampling rate : 8/11.025/16/22.05/32/44.1/48 kHz
Number of channel : Monaural (Stereo: The same audio signals are output from both L/R.)
Modulation input Number of data bit : 16-bit
Sampling rate : 32/44.1/48 kHz
Number of channel : Monaural (Stereo: The audio signal from L is input.)
All stated specifications are subject to change without notice or obligation.
A-6668-3EX © 2008 Icom Inc.

Icom IC-7200 Specifications

Ports & interfaces

connector type	USB B type
interface	USB 2.0/1.1
serial speed	300/1200/4800/9600/19200 bps

Power

power supply	Self power

Audio

received audio output number of data bit	16-bit
received audio output sampling rate	8/11.025/16/22.05/32/44.1/48 kHz
modulation input number of data bit	16-bit
modulation input sampling rate	32/44.1/48 kHz
