2 - 2
• TOP VIEW
FILTER unit
Current transformer
(L1: LR-364)
C-MOS IC
(IC14: TC74AC04F)
FAN
TUNER unit
Fan control circuit
Antenna tuner CPU
(IC5: M38022M2-138FP)
CTRL unit
Common filter
(L501, L502: LR-386)
PA unit
Drive amplifier
