27
7
SPECIFICATIONS
General D
• Frequency range:
Channel spacing: 25 kHz 118.000 to 136.975 MHz
Channel spacing: 8.33 kHz 118.000 to 136.992 MHz
Weather channel* 161.650 to 163.275 MHz
• Channel spacing: 25 kHz or 8.33 kHz
• Frequency stability:
IC-A220 ±5 ppm ( –20°C to +55°C;
–4°F to +131°F)
IC-A220E ±1 ppm (0˚C to +40˚C)
• Operating temperature: –20˚C to +55˚C;
–4˚F to +131˚F
• Antenna impedance: 50 ø
•
Number of memory channels:
20 regular memory channels
50 group memory channels
20 history memory channels
10 weather memory channels*
10 GPS memory channels
• Mode:
AM 6K00A3E/5K60A3E
FM* 16K0G3E
• Power supply requirement: 13.80 V/27.50 V DC
(negative ground)
• Dimensions: 160
(W)✕34 (H)✕271 (D) mm;
(projections not included) 6.3 (W)✕1.3 (H)✕10.7
(D) inches
• Weight (approximately): 1.0 kg; 2.2 lb
Transmitter D
• Output power:
IC-A220 8 W (Carrier power)
IC-A220E 6 W (Carrier power)
• Spurious emissions:
IC-A220 –60 dBc
IC-A220E –36 dBm (harmonics)
–46 dBm (non-harmonics)
• Microphone impedance: 600 ø
• Modulation limiting:
IC-A220 70% (Maximum 98%)
IC-A220E 85% (Maximum 95%)
Receiver D
• Receive system: Double conversion
superheterodyne
• Intermediate frequencies: 1st 38.85 MHz
2nd 450 kHz
• Sensitivity:
IC-A220 AM Less than 2 μV (pd)
at 6 dB S/N
FM* Less than 1.4 μV
at 12 dB SINAD
IC-A220E Less than –101 dBm
at 12 dB SINAD
*For only U.S.A. version transceivers, receiving only.
Use of 8.33 kHz Channel Spacing of this radio is strictly prohibited and shall not be used in Canada.
