Icom IC-A5 Service Manual

6 - 3
S.=Surface mount
IC1 1110003490 S.IC TA31136FN (D,EL)
IC2 1130006220 S.IC TC4W53FU (TE12L)
IC3 1130008830 S.IC TB31207AFN (EL)
IC4 1110003690 S.IC M62354GP 75EC
IC5 1130007570 S.IC BU4094BCFV-E2
IC6 1110001810 S.IC TA7368F (TP1)
IC13 1110002400 S.IC NJM2107F-TE1
IC14 1110002400 S.IC NJM2107F-TE1
IC505 1110004490 S.IC M62429FP 700C
IC510 1130007650 S.IC TC75W51FU (TE12L)
Q1 1590001520 S.TRANSISTOR UMS1 TL
Q2 1560001050 S.FET 2SK2974
Q3 1560001020 S.FET 2SK2973 (MTS101P)
Q4 1530003340 S.TRANSISTOR 2SC3357-T2 RF
Q5 1530003280 S.TRANSISTOR 2SC4211-6-TL
Q6 1530002560 S.TRANSISTOR 2SC4403-3-TL
Q7 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q8 1530003280 S.TRANSISTOR 2SC4211-6-TL
Q10 1540000520 S.TRANSISTOR 2SD1819A (TX) R
Q11 1580000650 S.FET 3SK230-T2 U1B
Q12 1580000400 S.FET 3SK151-Y (TE85R)
Q13 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q14 1540000520 S.TRANSISTOR 2SD1819A (TX) R
Q15 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q16 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q17 1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
Q18 1530003280 S.TRANSISTOR 2SC4211-6-TL
Q19 1590001140 S.TRANSISTOR UN9210 (TX) [A23] only
Q20 1590001690 S.TRANSISTOR UN9115 (TX)
Q21 1590001140 S.TRANSISTOR UN9210 (TX)
Q22 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q23 1590001140 S.TRANSISTOR UN9210 (TX)
Q24 1590002580 S.FET HAT1024R-EL
Q25 1520000460 S.TRANSISTOR 2SB1132 T100 R
Q26 1590001150 S.TRANSISTOR UN9211 (TX)
Q27 1530002560 S.TRANSISTOR 2SC4403-3-TL
Q28 1530002560 S.TRANSISTOR 2SC4403-3-TL
Q29 1530002560 S.TRANSISTOR 2SC4403-3-TL
Q30 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q31 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q32 1530002920 S.TRANSISTOR 2SC4226-T2 R25
Q33 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q34 1590001140 S.TRANSISTOR UN9210 (TX)
Q35 1520000650 S.TRANSISTOR 2SB1201-S-TL
Q36 1590001170 S.TRANSISTOR XP1501-(TX) .AB
D1 1790000620 S.DIODE MA77 (TX)
D2 1790000660 S.DIODE MA728 (TX)
D3 1790000660 S.DIODE MA728 (TX)
D4 1750000460 S.DIODE 1SV246-TL
D5 1750000460 S.DIODE 1SV246-TL
D6 1790000620 S.DIODE MA77 (TX)
D7 1790001280 S.DIODE MA111 (TX)
D8 1790000620 S.DIODE MA77 (TX)
D9 1790000620 S.DIODE MA77 (TX)
D13 1790001290 S.VARICAP MA304 (TX)
D14 1790001290 S.VARICAP MA304 (TX)
D15 1790001290 S.VARICAP MA304 (TX)
D16 1790001290 S.VARICAP MA304 (TX)
D17 1790000620 S.DIODE MA77 (TX)
D18 1790001280 S.DIODE MA111 (TX)
D19 1750000540 S.DIODE RB060L-40 TE-25
D20 1790000670 S.DIODE SB07-03C-TB
D21 1790000860 S.DIODE MA133 (TX)
D22 1790001240 S.DIODE MA2S728-(TX)
D23 1790000860 S.DIODE MA133 (TX)
D24 1790001290 S.VARICAP MA304 (TX)
D25 1790000620 S.DIODE MA77 (TX)
D26 1720000670 S.VARICAP HVU17TRF
D27 1790001280 S.DIODE MA111 (TX)
D100 1730002270 S.ZENER MA8024 (TX)
FI1 2030000090 S.MONOLITH FL-325 (30.050 MHz)
FI2 2020001780 S.CERAMIC CFWC450E
X1 6070000210
S.DISCRIMINATOR CDBCA450CX24
X2 6050011040 S.XTAL CR-683 (29.600 MHz)
L1 6200008280 S.COIL 0.30-1.7-7TL 50N
L2 6200008300 S.COIL 0.35-1.6-9TL 65N
L3 6200008300 S.COIL 0.35-1.6-9TL 65N
L4 6200001520 S.COIL MLF2012D R82K-T
L5 6200008260 S.COIL 0.30-1.7-8TL 60N
L6 6200008340 S.COIL 0.26-1.1-5TR 19.5N
L7 6200008400 S.COIL 0.35-1.6-6TL 36N
L8 6200005710 S.COIL ELJRE 27NG-F
L9 6200003590 S.COIL EXCCL3225U1
L10 6200002370 S.COIL LQN 1A 39NJ04
L11 6200006670 S.COIL ELJRE 68NG-F
L12 6200008190 S.COIL 0.25-1.9-8TL 80N
L13 6200001630 S.COIL ELJNC R10K-F
L14 6200002190 S.COIL MLF2012A 4R7K-T
L15 6200008170 S.COIL 0.35-1.6-8TL 54N
L16 6200008280 S.COIL 0.30-1.7-7TL 50N
L18 6200007750 S.COIL LQN21A 56NJ04
L21 6200008090 S.COIL LQN21A 68NJ04
L22 6200007760 S.COIL LQN21A 82NJ04
L23 6200008090 S.COIL LQN21A 68NJ04
L24 6200002750 S.COIL MLF2012A 2R2K-T
L25 6200003590 S.COIL EXCCL3225U1
L26 6200008420 S.COIL HF50ACC 453215P-T
L28 6200003590 S.COIL EXCCL3225U1
L29 6200002240 S.COIL ELJFC 2R2K-F
L31 6200002240 S.COIL ELJFC 2R2K-F
L32 6200002240 S.COIL ELJFC 2R2K-F
L33 6200002240 S.COIL ELJFC 2R2K-F
L34 6200002240 S.COIL ELJFC 2R2K-F
L35 6200003590 S.COIL EXCCL3225U1
L36 6200002240 S.COIL ELJFC 2R2K-F
L37 6200005510 S.COIL ELJND R27J-F
L38 6200005510 S.COIL ELJND R27J-F
L39 6200007000 S.COIL ELJRE 82NG-F
L40 6130002950 S.COIL LB-342
L41 6200004480 S.COIL MLF1608D R82K-T
L42 6200002190 S.COIL MLF2012A 4R7K-T
L43 6200003710 S.COIL NL 252018T-2R7J
L44 6200001040 S.COIL MLF2012E 6R8M-T
L300 6200003540 S.COIL MLF1608D R22K-T
L301 6200003540 S.COIL MLF1608D R22K-T
R2 7030000260 S.RESISTOR MCR10EZHJ 47 Ω (470)
R3 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R4 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R5 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R6 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R7 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R8 7030003370 S.RESISTOR ERJ3GEYJ 271 V (270 Ω)
R9 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R10 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R11 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R12 7030003640 S.RESISTOR ERJ3GEYJ 473 V (47 kΩ)
R13 7030003660 S.RESISTOR ERJ3GEYJ 683 V (68 kΩ)
R14 7030003600 S.RESISTOR ERJ3GEYJ 223 V (22 kΩ)
R15 7030003260 S.RESISTOR ERJ3GEYJ 330 V (33 Ω)
R16 7310003600 S.TRIMMER EVM-1XSX50 B34 (303)
R17 7030003570 S.RESISTOR ERJ3GEYJ 123 V (12 kΩ)
R18 7030003260 S.RESISTOR ERJ3GEYJ 330 V (33 Ω)
R19 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R20 7030003290 S.RESISTOR ERJ3GEYJ 560 V (56 Ω)
R21 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R22 7030003480 S.RESISTOR ERJ3GEYJ 222 V (2.2 kΩ)
R23 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R24 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R25 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R26 7030003680 S.RESISTOR ERJ3GEYJ 104 V (100 kΩ)
R27 7030003440 S.RESISTOR ERJ3GEYJ 102 V (1 kΩ)
R28 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R29 7030003580 S.RESISTOR ERJ3GEYJ 153 V (15 kΩ)
R30 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R31 7030003620 S.RESISTOR ERJ3GEYJ 333 V (33 kΩ)
R32 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R33 7030003360 S.RESISTOR ERJ3GEYJ 221 V (220 Ω)
R34 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R35 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R36 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R37 7030003400 S.RESISTOR ERJ3GEYJ 471 V (470 Ω)
R38 7030003320 S.RESISTOR ERJ3GEYJ 101 V (100 Ω)
R39 7030003560 S.RESISTOR ERJ3GEYJ 103 V (10 kΩ)
R40 7030003500 S.RESISTOR ERJ3GEYJ 332 V (3.3 kΩ)
REF ORDER
DESCRIPTION
NO. NO.
[RF UNIT]
REF ORDER
DESCRIPTION
NO. NO.
[RF UNIT]
