Icom IC-F24 Service Manual

6 - 5
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[CHASSIS UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C324 4030017420 S.CER ECJ0EC1H470J T 85/13.7
C325 4550006250 S.TAN TEESVA 1A 106M8L T 90.6/17.2
C326 4510006940 S.ELE EEVFC0J101P B 87.8/8.9
C333 4030017420 S.CER ECJ0EC1H470J B 76.8/39.9
C335 4030018860 S.CER ECJ0EB0J105K B 57.2/21.1
C339 4030016930 S.CER ECJ0EB1A104K B 5.9/17.2
C340 4030016930 S.CER ECJ0EB1A104K B 9.3/12.5
C341 4030016930 S.CER ECJ0EB1A104K B 5.9/10.1
C342 4030017630 S.CER ECJ0EC1H120J B 18.3/4.2
C343 4030017580 S.CER ECJ0EC1H060C B 5.6/4.2
C344 4030017640 S.CER ECJ0EC1H150J B 7.6/9.1
C345 4030016930 S.CER ECJ0EB1A104K B 11/11.2
C346 4030016930 S.CER ECJ0EB1A104K B 11/10.1
C347 4030016790 S.CER ECJ0EB1C103K T 8.8/6.5
C348 4030016930 S.CER ECJ0EB1A104K T 6/10
C349 4030016930 S.CER ECJ0EB1A104K T 21.3/14.9
C350 4030017460 S.CER ECJ0EB1E102K T 59.4/43.4
C354 4030017460 S.CER ECJ0EB1E102K T 14.2/24.4
C355 4030018080 S.CER ECJ0EB1H182K T 42.9/22.7
C356 4030018910 S.CER C1608 JB 0J 475K-T T 35.3/20.6
C357 4030017400 S.CER ECJ0EC1H220J T 79/25.5
J1 6510021900 S.CNR BM02B-ASRS-TF T 86.6/6.8
J2 6450001680 CNR HSJ1122-010010
J3 6450002250 CNR HSJ1456-010320
J4 6510018430 S.CNR AXN330C038P B 11.8/30.6
J5 6510021900 S.CNR BM02B-ASRS-TF T 50.4/11.7
[US2S], [US3S], [EU2S], [GE2S], [GE3S] only
F1 5210000830 S.FUS ERBFE3R00U T 98/14.5
DS1 5040002670 S.LED CL-165HR/YG T 102.8/12.4
MC1 7700002540 MIC SKP-4538
S1 2260002840 SW SKHLLFA010
S2 2260002800 S.SW SW-167 (SKQTLAE010) B 99.4/44.2
S3 2260002800 S.SW SW-167 (SKQTLAE010) B 60.9/44.2
S4 2250000490 ECR TP70TF5163-15.9F-2775
[US2], [US3], [EU2], [GE2], [GE3] only
EP1 6910015370 S.BEA ACZ1005Y-102-T T 57/29.9
EP2 0910057942 PCB B 6161B
EP3 6910015370 S.BEA ACZ1005Y-102-T T 34.7/32
J1 6910015910 CNR ANT CONNECTOR-104
J2 6910015860 CNR IMSA-6277S-02A-G
S1 2260002870 SW AS-243-A13
[US2S], [US3S], [EU2S], [GE2S], [GE3S] only
SP1 2510001060 SP K036NA500-47
W1 8900009640 CBL OPC-963
W2 8900009640 CBL OPC-963
[US2S], [US3S], [EU2S], [GE2S], [GE3S] only
[ANT UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
L601 6200008240 S.COL 0.30-0.9-5TL 14N B 7.2/12.5
C601 4030017600 S.CER ECJ0EC1H080C B 5.8/15.3
EP601 0910057920 PCB B 6210
[CONNECT UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C501 4030017460 S.CER ECJ0EB1E102K T 18.3/15.3
C502 4030016930 S.CER ECJ0EB1A104K T 9.3/15.3
J501 6910016390 CNR IMSA-9230B-1-02Z145-PT1
EP501 0910057930 PCB B 6160
S.=Surface mount
