6-3 TRANSMIT ADJUSTMENT (continued)
Select an adjustment item using [
↑
] / [
↓
] keys, then set to the specifi ed value using [
←
] / [
→
] keys on the connected PC's keyboard.
ADJUSTMENT ADJUSTMENT CONDITION
MEASUREMENT
VALUE
UNIT OPERATION
CTCSS/DTCS
DEVIATION
[CTCSS/DTCS]
1
• Channel : CH 19
Top
panel
Connect an FM deviation meter to
the antenna connector through
an attenuator.
±0.68 to
±
0.72 kHz
(Other than
[FRG-01])
±0.53 to ±0.57 kHz
([FRG-01])
• No audio applied to the JIG cable.
• Set the FM deviation meter to same condi-
tion as "MODULATION BALANCE."
• Transmitting
2/5 TONE
DTMF***
[S.Tone]
1
• Channel : CH 7
• Set the FM deviation meter to same condi-
tion as "MODULATION BALANCE."
• Transmitting
Top
panel
Connect an FM deviation meter to
the antenna connector through
an attenuator.
±1.50 kHz
2
***; [F3160] series only.
