7 - 6
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT] (for F3060 series)
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C224 4030017790 S.CER ECJ0EB1E682K B 66/35.4
C225 4030016940 S.CER ECJ0EB1A393K B 66.5/38.4
C226 4550006250 S.TAN TEESVA 1A 106M8R B 41.2/39.1
C227 4030017460 S.CER ECJ0EB1E102K B 44.7/36.3
C228 4550000460 S.TAN TEESVA 1C 105M8R T 58.4/42.1
C229 4550000460 S.TAN TEESVA 1C 105M8R B 60.4/39.7
C230 4030017460 S.CER ECJ0EB1E102K B 56.4/41.2
C231 4030017420 S.CER ECJ0EC1H470J T 57/35.9
C232 4030017420 S.CER ECJ0EC1H470J T 57.7/33.5
C233 4030017420 S.CER ECJ0EC1H470J T 58.7/35.6
C234 4030017420 S.CER ECJ0EC1H470J T 59/37.4
C235 4030017420 S.CER ECJ0EC1H470J T 44.7/35.3
C236 4030017420 S.CER ECJ0EC1H470J T 43.3/33
C237 4030016970 S.CER ECJ0EB1C223K T 43.9/39.4
C238 4030016930 S.CER ECJ0EB1A104K T 48/32
C239 4030017420 S.CER ECJ0EC1H470J T 43.1/29.2
C240 4030017420 S.CER ECJ0EC1H470J T 55.2/39.3
C241 4030017750 S.CER ECJ0EB1E122K T 57/37.6
C242 4030016930 S.CER ECJ0EB1A104K Except [FRG-01] T 55.2/34.2
4030018860 S.CER ECJ0EB0J105K [FRG-01] T 55.2/34.2
C243 4030016930 S.CER ECJ0EB1A104K Except [FRG-01] T 48/36.8
4030018860 S.CER ECJ0EB0J105K [FRG-01] T 48/36.8
C244 4030017440 S.CER ECJ0EC1H221J Except [FRG-01] B 44.9/5
4030017730 S.CER ECJ0EB1E471K [FRG-01] B 44.9/5
C245 4030017900 S.CER ECJ0EB1C123K [FRG-01] B 45.5/6.9
4030018080 S.CER ECJ0EB1H182K Except [FRG-01] B 45.5/6.9
C246 4030016930 S.CER ECJ0EB1A104K T 47.7/10.1
C247 4030016930 S.CER ECJ0EB1A104K B 52.4/9.9
C248 4030017710 S.CER ECJ0EC1H181J B 46.4/39.2
C249 4030016930 S.CER ECJ0EB1A104K B 44/39.3
C250 4030017740 S.CER ECJ0EB1E821K Except [FRG-01] B 53.3/6.9
4030017910 S.CER ECJ0EB1H152K [FRG-01] B 53.3/6.9
C251 4030016930 S.CER ECJ0EB1A104K B 41.6/33.5
C252 4030016930 S.CER ECJ0EB1A104K B 39.6/23.2
C253 4030016930 S.CER ECJ0EB1A104K B 47.9/20
C254 4030016930 S.CER ECJ0EB1A104K B 42.9/23
C255 4030016790 S.CER ECJ0EB1C103K B 37.2/6.6
C256 4030017760 S.CER ECJ0EB1H222K T 39.6/6.2
C257 4030016930 S.CER ECJ0EB1A104K B 45/8.1
C258 4030017730 S.CER ECJ0EB1E471K B 47.6/30.7
C259 4550006250 S.TAN TEESVA 1A 106M8R T 55.7/23.1
C260 4550006250 S.TAN TEESVA 1A 106M8R T 56.4/17.9
C261 4030018860 S.CER ECJ0EB0J105K T 48.3/23.7
C264 4030017460 S.CER ECJ0EB1E102K B 36.6/8.8
C265 4030016930 S.CER ECJ0EB1A104K T 40.3/30.5
C266 4030016930 S.CER ECJ0EB1A104K Except [FRG-01] T 40.7/27.3
4030018860 S.CER ECJ0EB0J105K [FRG-01] T 40.7/27.3
C267 4030017730 S.CER ECJ0EB1E471K B 46.7/28.9
C268 4030016960 S.CER ECJ0EB1C183K B 47.1/25.4
C269 4030016960 S.CER ECJ0EB1C183K B 47.1/23.8
C272 4030016930 S.CER ECJ0EB1A104K T 7.3/14.2
C273 4030017460 S.CER ECJ0EB1E102K B 7/9.2
C276 4030017460 S.CER ECJ0EB1E102K B 100.2/6.5
C277 4550007080 S.TAN TEESVA 1C 106M8R B 104/9.5
C278 4030017460 S.CER ECJ0EB1E102K B 101.4/6.9
C279 4030016790 S.CER ECJ0EB1C103K B 98.2/7.6
C280 4030016930 S.CER ECJ0EB1A104K T 105.4/10.9
C281 4030016790 S.CER ECJ0EB1C103K T 97.9/6.2
C282 4550005980 S.TAN TEESVA 1A 475M8R T 103.1/12.5
C283 4030017460 S.CER ECJ0EB1E102K T 96/11.4
C284 4030016790 S.CER ECJ0EB1C103K B 93.8/10.2
C285 4030017460 S.CER ECJ0EB1E102K B 92.5/9.2
C286 4030017460 S.CER ECJ0EB1E102K B 90.6/7.3
C287 4030016790 S.CER ECJ0EB1C103K B 88.9/10
C288 4030017460 S.CER ECJ0EB1E102K B 89.7/7.3
C289 4030017460 S.CER ECJ0EB1E102K T 90.3/11.6
C290 4030016790 S.CER ECJ0EB1C103K T 91.4/7.6
C291 4030017460 S.CER ECJ0EB1E102K T 88.8/11.2
C292 4030017460 S.CER ECJ0EB1E102K B 99.1/6.5
C293 4550006480 S.TAN TEESVA 1C 475M8R B 61.4/8.8
C294 4030016930 S.CER ECJ0EB1A104K B 62.5/10.4
C295 4030016930 S.CER ECJ0EB1A104K B 67.9/21
C296 4030017460 S.CER ECJ0EB1E102K B 68.8/21
C297 4030017460 S.CER ECJ0EB1E102K B 62.8/29.4
C298 4030017460 S.CER ECJ0EB1E102K T 59.7/30.6
C299 4030016930 S.CER ECJ0EB1A104K B 33/34.5
C300 4030017420 S.CER ECJ0EC1H470J B 33/33.6
C301 4030017750 S.CER ECJ0EB1E122K B 25.5/33.4
C302 4030016930 S.CER ECJ0EB1A104K B 27.3/33.4
C303 4030016960 S.CER ECJ0EB1C183K B 23.7/33.4
C304 4030016930 S.CER ECJ0EB1A104K T 8.3/21.7
C305 4030017420 S.CER ECJ0EC1H470J T 25.5/35.8
C306 4030017430 S.CER ECJ0EC1H101J B 22.1/38
C307 4030017910 S.CER ECJ0EB1H152K B 22.1/36.2
C308 4030017420 S.CER ECJ0EC1H470J B 22.1/41.7
C309 4030017690 S.CER ECJ0EC1H121J T 26/40.7
C310 4030017760 S.CER ECJ0EB1H222K B 22.1/40.8
C311 4030017460 S.CER ECJ0EB1E102K B 18.9/41.7
C312 4030016930 S.CER ECJ0EB1A104K T 24.3/35.4
C313 4030016930 S.CER ECJ0EB1A104K B 39.5/24.7
C314 4030017460 S.CER ECJ0EB1E102K T 19/41.4
C315 4030018560 S.CER C2012 JB 1A 475K-T B 30.5/33.4
C316 4030016930 S.CER ECJ0EB1A104K T 28.5/22.2
C317 4030016930 S.CER ECJ0EB1A104K B 30.1/5.2
C318 4030016930 S.CER ECJ0EB1A104K T 103.3/35.6
C319 4550006780 S.TAN TEESVB2 0J 476M8R T 94.6/35.2
C320 4030017420 S.CER ECJ0EC1H470J T 24/16.8
C321 4030017420 S.CER ECJ0EC1H470J B 87.5/11.4
C322 4030016930 S.CER ECJ0EB1A104K B 12.9/23.2
C323 4030016930 S.CER ECJ0EB1A104K B 12.9/21.4
C324 4030016930 S.CER ECJ0EB1A104K B 9.2/21.4
C325 4030016930 S.CER ECJ0EB1A104K B 12.8/26.6
C326 4030017030 S.CER ECJ0EB1A273K B 14.4/30.9
C328 4030017420 S.CER ECJ0EC1H470J T 36.4/23.1
S.=Surface mount
[MAIN UNIT] (for F3060 series)
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C329 4030017580 S.CER ECJ0EC1H060C T 4.8/39
C330 4030017630 S.CER ECJ0EC1H120J T 4.8/25.5
C331 4030017640 S.CER ECJ0EC1H150J B 11.1/32.1
C332 4030017420 S.CER ECJ0EC1H470J T 20.9/25.2
C333 4030017420 S.CER ECJ0EC1H470J B 25.8/31.8
C336 4030017420 S.CER ECJ0EC1H470J B 36.6/32.7
C339 4030017420 S.CER ECJ0EC1H470J T 38.2/25.1
C340 4030017420 S.CER ECJ0EC1H470J T 35.3/27.8
C341 4030017460 S.CER ECJ0EB1E102K T 23.7/33.8
C342 4030016930 S.CER ECJ0EB1A104K B 14.5/18.6
C343 4030016930 S.CER ECJ0EB1A104K T 10.6/25.6
C344 4030016790 S.CER ECJ0EB1C103K T 89.1/18.9
C345 4030017460 S.CER ECJ0EB1E102K T 88.2/18.9
C346 4030017630 S.CER ECJ0EC1H120J B 88.4/17.2
C347 4030016790 S.CER ECJ0EB1C103K B 88.4/15.6
C348 4030017460 S.CER ECJ0EB1E102K B 89.4/15.6
C349 4030017460 S.CER ECJ0EB1E102K B 91.2/14.7
C354 4030017420 S.CER ECJ0EC1H470J T 30.3/22.9
C355 4030017420 S.CER ECJ0EC1H470J T 21.8/17.7
C358 4030017420 S.CER ECJ0EC1H470J B 33.4/12.3
C359 4030017420 S.CER ECJ0EC1H470J B 33.9/15.4
C360 4030017420 S.CER ECJ0EC1H470J T 25.5/17.6
C361 4030017420 S.CER ECJ0EC1H470J T 29.7/16
C363 4030017420 S.CER ECJ0EC1H470J T 29.8/12.1
C364 4030017420 S.CER ECJ0EC1H470J T 27.9/12.7
C365 4030017460 S.CER ECJ0EB1E102K B 59.2/4.5
C366 4030018860 S.CER ECJ0EB0J105K B 36.2/16.7
C367 4030016930 S.CER ECJ0EB1A104K B 31/39.4
C368 4030016930 S.CER ECJ0EB1A104K B 42.9/25.7
C369 4030016930 S.CER ECJ0EB1A104K B 29.2/38.5
C370 4030016790 S.CER ECJ0EB1C103K T 45.9/24.5
C371 4030017460 S.CER ECJ0EB1E102K T 53.9/24.4
C372 4030016930 S.CER ECJ0EB1A104K T 53.9/23.5
C373 4030016930 S.CER ECJ0EB1A104K B 29.2/36.7
C376 4030017460 S.CER ECJ0EB1E102K B 88.7/12.9
C377 4030016930 S.CER ECJ0EB1A104K B 69.1/34.1
C378 4030016790 S.CER ECJ0EB1C103K B 87.6/23
C379 4030016790 S.CER ECJ0EB1C103K T 94.9/31.7
C380 4030011600 S.CER C1608 JB 1E 104K-T B 105.7/10.4
C381 4030017490 S.CER C1608 JB 1A 105K-T B 96.6/7.2
C382 4030016790 S.CER ECJ0EB1C103K B 13.1/33.7
C383 4030017460 S.CER ECJ0EB1E102K T 92.7/14.1
C384 4030017420 S.CER ECJ0EC1H470J T 92.7/13.2
C385 4030016930 S.CER ECJ0EB1A104K B 7.2/25.9
C386 4550006250 S.TAN TEESVA 1A 106M8R B 76/14.4
C387 4030017460 S.CER ECJ0EB1E102K B 77.2/17.4
C393 4030017460 S.CER ECJ0EB1E102K T 39.7/19.6
C405 4030016930 S.CER ECJ0EB1A104K T 73.9/43.6
C406 4030016930 S.CER ECJ0EB1A104K T 72.4/41.4
C407 4030017460 S.CER ECJ0EB1E102K T 19.2/24.3
C408 4550005980 S.TAN TEESVA 1A 475M8R B 5.4/33
C409 4030016930 S.CER ECJ0EB1A104K B 13.2/10.7
C412 4030017660 S.CER ECJ0EC1H330J B 1.6/14.6
C413 4030017660 S.CER ECJ0EC1H330J B 1.6/17.1
C414 4030016790 S.CER ECJ0EB1C103K B 7/10.9
C417 4030017460 S.CER ECJ0EB1E102K B 99.5/31.2
C418 4030017460 S.CER ECJ0EB1E102K B 98.3/30.4
C420 4030017780 S.CER ECJ0EB1E472K B 53.9/5.7
C421 4030017460 S.CER ECJ0EB1E102K T 14.9/18.8
C422 4030016930 S.CER ECJ0EB1A104K T 40.2/21.4
C424 4030016790 S.CER ECJ0EB1C103K T 58.9/23.6
C425 4030017460 S.CER ECJ0EB1E102K T 97.1/23.2
C426 4030017380 S.CER ECJ0EC1H050B B 79/18
C427 4030017460 S.CER ECJ0EB1E102K T 85/20
C428 4030017460 S.CER ECJ0EB1E102K T 36.1/29.7
C429 4030018860 S.CER ECJ0EB0J105K B 34.5/5.9
C430 4030018860 S.CER ECJ0EB0J105K T 13.7/23.7
C431 4030017460 S.CER ECJ0EB1E102K T 54.7/30.5
C432 4030017340 S.CER ECJ0EC1H010B
[F3062T], [F3062S EUR-01], [FRG-01] only T 104/27.1
J1 6510025220 S.CNR AXK540145J T 14.5/36.4
J2 6510025220 S.CNR AXK540145J T 36.5/36.4
J3 6510025190 S.CNR IMSA-9639S-20Y905 T 52.3/12.7
J4 6510023970 S.CNR 20P3.5-JMCS-G-B-TF (N) T 109/34.7
S3 2260002840 SW SKHLLFA010
S4 2260002800 S.SW SW-167 (SKQTLAE010) T 53.5/44.2
S5 2260002800 S.SW SW-167 (SKQTLAE010) T 63.4/44.2
S6 2260002800 S.SW SW-167 (SKQTLAE010) T 106.4/44.2
EP1 6910015370 S.BEA ACZ1005Y-102-T B 56.6/29.9
EP3 6910015370 S.BEA ACZ1005Y-102-T B 45.9/36.8
EP4 6910015600 S.BEA ACZ1005Y-241 (240) B 56.4/39.6
EP5 6910015370 S.BEA ACZ1005Y-102-T B 62.6/21.7
