5 - 7
ADJUSTMENT
TRANSCEIVER’S
CONDITION
OPERATION
ADJUSTMENT
ITEM
VALUE
RECEIVE
SENSITIVITY
NOTE:
“RECEIVE SENSITIVITY” must be adjusted before “S-METER.” Otherwise, “S-METER” will not beadjusted
properly. When “RECEIVE SENSITIVITY” is re-adjusted, “S-METER” must be also re-adjusted.
1 • Channel : 1-27*
1-28**
• Receiving
• Connect an SSG to the antenna connec-
tor and set it as;
Frequency : 400 MHz [400 MHz band]
350 MHz [350 MHz band]
Level
†
: +20 dBµ (–87 dBm)
Modulation : 1 kHz
Deviation : ±3.0 kHz*
±1.5 kHz**
[BPF C ALL]
Push [ENTER]
(Automatic
adjustment)
S-METER NOTE: When “RECEIVE SENSITIVITY” is re-adjusted, “S-METER” must be also re-adjusted.
1 • Channel : 1-29*
1-30**
• Receiving
• Connect an SSG to the antenna connec-
tor and set it as;
Frequency : 400 MHz [400 MHz band]
350 MHz [350 MHz band]
Level
†
: +23 dBµ (–84 dBm)
Modulation : 1 kHz
Deviation : ±3.0 kHz*
±1.5 kHz**
[RSSI S3 Level]
Push [ENTER]
(Automatic
adjustment)
2• Set the SSG as;
Level
†
: –7 dBµ (–114 dBm)
[RSSI S1 Level]
SQUELCH NOTE: When “RECEIVE SENSITIVITY” is re-adjusted, “SQUELCH” must be also re-adjusted.
1 • Channel : 1-31*
1-32**
• Receiving
1) Connect an SSG to the antenna con-
nector and set it as;
Frequency : 400 MHz [400 MHz band]
350 MHz [350 MHz band]
Level
†
: –14 dBµ (–121 dBm)
Modulation : 1 kHz
Deviation : ±3.0 kHz*
±1.5 kHz**
2) Once close the squelch by increasing the
[SQL] value, and then decrease the value
to open the squelch.
[SQL]
Squelch opens
(Push [ENTER]
to store the
value
)
†
; The output level of the standard signal generator (SSG) is indicated as the SSG’s open circuit.
*: For all models except [USA]. **: For [USA]
5-4 RECEIVE ADJUSTMENTS
1) Select an adjustment item using [
↑
]/[
↓
] on the PC's keyboard.
2) Set or modify the adjustment value as specifi ed using [
←
]/[
→
] on the PC's keyboard, then push [ENTER].
To Next Page
