7 - 1
F3/S
F4/S
MP1 8010016822 1922 chassis-2 1
MP2 8210014561 1922 front panel assembly-1 (F3) 1
8210015151 2065 front panel assembly-1 (F3S) 1
MP4 8210014330 1922 contact base 1
MP5 8610010420 Knob N-261 1
MP6 8930042110 1922 10-key (F3) 1
8930043970 2065 7-key (F3S) 1
MP7 8930042070 1922 MIC cap 1
MP9 8930042030 1922 main seal 1
MP10 8110006050 1922 OPT cover 1
MP11 8930042050 1922 DC cap 1
MP12 8930042090 1922 plus terminal 1
MP13 8930042080 1922 minus terminal 1
MP14 8950004671 ANT connector-101A 1
MP17 8310040690 1922 window plate (D) 1
MP19 8930042720
1922 rear sheet (A)
e
-GEN
(F3) 1
8930042360
1922 rear sheet
u-Ò-W (F3) 1
8930042760
1922 rear sheet (E)
u-Ó-W 16 ch (F3) 1
8930043320
1922 rear sheet (G)
u-Ò-N (F3) 1
8930043330
1922 rear sheet (H)
u-Ó-N (F3) 1
8930045660
1922 rear sheet (AC)
u-Ó-W
2 BANK (F3)
1
8930044750
1922 rear sheet (U)
e
-EUR
(F3) 1
8930044350
1922 rear sheet (K)
e
-GEN
(F3S) 1
8930044360
1922 rear sheet (L)
u-Ò-W (F3S) 1
8930044370
1922 rear sheet (M)
u-Ó-W (F3S) 1
8930044380
1922 rear sheet (N)
u-Ò-N (F3S) 1
8930047450
1922 rear sheet (O)
u-Ó-N (F3S) 1
8930045670
1922 rear sheet (AD)
e
-EUR
(F3S) 1
MP21 8930042350 1922 MIC sheet 1
MP22 8930042560 1922 OPT sheet 1
MP24 8830001250 Nut 1
MP25 8830001010 Hex nut (A) 1
MP26 8810000100 Screw PH M2 × 4 ZK 2
MP27 8810009510 Screw PH B0 2 × 4 NI-ZU (BT) 6
MP28 8810009510 Screw PH B0 2 × 4 NI-ZU (BT) 1
MP29 8810009510 Screw PH B0 2 × 4 NI-ZU (BT) 2
MP30 8810009560 Screw PH B0 2 × 6 ZK (BT) 2
MP31 8810009560 Screw PH B0 2 × 6 ZK (BT) 2
MP34 8930043210 1922 A-rear sheet 1
MP35 8930043760 1923 MIC seal 1
MP36 8930043860 Sponge (FH) 1
MP37 8860001060 1989 antenna rug plate 1
MP38 8510010870 1922 shield cover e (F3S) 1
MP39 8930043610 Isolating sheet (EZ) 1
REF ORDER
DESCRIPTION
NO. NO.
[CHASSIS PARTS] for IC-F3/S
Ò, [L]:
L-band
, Ó:
H-band
, [ML]: ML-band, [MH]: MH-band, [H
1
]: H
1
-band, [H
2
]: H
2
-band
CE: CE-type, W:
W-type
, N:
N-type
, u:
EIA/TIA version
, e-GEN, e-EUR:
ETS/CEPT version
Screw abbreviations : PH: Pan head A0, B0: Self-tapping NI: Nickel ZK: Black
SECTION 7 MECHANICAL PARTS AND DISASSEMBLY
7-1 CABINET PARTS
QTY.
MP1 8010016822 1922 Chassis-2 1
MP2 8210014731 1922 Front panel (B) assembly-1 (F4) 1
8210015161 2066 Front panel (A) assembly-1 (F4S) 1
MP4 8210014330 1922 Contact base 1
MP5 8610010420 Knob N-261 1
MP6 8930042110 1922 10-key (F4) 1
8930043970 2065 7-key (F4S) 1
MP7 8930042070 1922 MIC cap 1
MP9 8930042030 1922 Main seal 1
MP10 8110006050 1922 OPT cover 1
MP11 8930042050 1922 DC cap 1
MP12 8930042090 1922 Plus terminal 1
MP13 8930042080 1922 Minus terminal 1
MP17 8310040690 1922 Window plate (D) 1
MP19 8930042750 1922 Rear sheet (D) e-GEN (F4) 1
8930044950 1922 Rear sheet (W) u-[L]-W (F4) 1
8930044960 1922 Rear sheet (X) u-[ML]-W (F4) 1
8930046680 1922 Rear sheet (AE) u-[L]-N (F4) 1
8930046690 1922 Rear sheet (AF) u-[ML]-N (F4) 1
8930047000 1922 Rear sheet (AK) u-[MH] (F4) 1
8930047010 1922 Rear sheet (AL) u-[H
1] (F4) 1
8930045550 1922 Rear sheet (AA) e-CE (F4) 1
8930044400 1922 Rear sheet (P) e-GEN (F4S) 1
8930046700 1922 Rear sheet (AG) u-[L]-N (F4S) 1
8930046710 1922 Rear sheet (AH) u-[ML]-N (F4S) 1
8930046810 1922 Rear sheet (AI) u-[L]-W (F4S) 1
8930048140 1922 Rear sheet (AT) u-[ML]-W (F4S) 1
8930047020 1922 Rear sheet (AM) u-[MH] (F4S) 1
8930047030 1922 Rear sheet (AN) u-[H
1]-N (F4S) 1
8930044460 1922 Rear sheet (AB) e-CE (F4S) 1
MP21 8930042350 1922 MIC sheet 1
MP22 8930042560 1922 OPT sheet 1
MP24 8830001250 Nut 1
MP25 8830001010 Hex nut (A) 1
MP26 8810000100 Screw PH M2 × 4 ZK 2
MP27 8810009510 Screw B0 2 × 4 NI-ZU (BT) 6
MP28 8810009510 Screw PH B0 2 × 4 NI-ZU (BT) 1
MP29 8810009510 Screw PH B0 2 × 4 NI-ZU (BT) 2
MP30 8810009560 Screw PH B0 2 × 6 ZK (BT) 2
MP31 8810009560 Screw PH B0 2 × 6 ZK (BT) 2
MP34 8930043210 1922 A-rear sheet 1
MP36 8950004671 ANT connector-101A 1
MP37 8510011260 1923 Shield cover 1
MP38 8930043760 1923 MIC seal 1
MP39 8930043860 Sponge (FH) 1
MP40 8930043610 Isolating sheet (EZ) 1
REF ORDER
DESCRIPTION
NO. NO.
QTY.
[CHASSIS PARTS] for IC-F4/S
DS1 5030001460 LCD LM-1462B 1
EP2 8930042590 LCD contact SRCN-1922-SP-N-W 1
MP1 8510011111 1922 VCO case-1 1
MP2 8510011101 1922 VCO cover-1 1
MP3 8930042060 1922 LCD holder 1
MP4 8210014380 1922 Reflector 1
MP5 8410002081 1922 PA heatsink-1 1
SP1 2510000960 K036NA500-26A27 1
REF ORDER
DESCRIPTION
NO. NO.
[MAIN UNIT] for IC-F3/S
QTY.
DS1 5030001460 LCD LM-1462B 1
EP2 8930042590 LCD contact SRCN-1922-SP-N-W 1
MP1 8510011111 1922 VCO case-1 1
MP2 8930042060 1922 LCD holder 1
MP3 8210014380 1922 Reflector 1
MP4 8410002081 1922 PA heatsink-1 1
MP6 8510011180 1922 VCO cover 1
MP7 8510011230 1923 VCO shield 1
MP8 8930046590 Sponge (FO) (F4S) only 1
SP1 2510000960 K036NA500-26A27 1
REF ORDER
DESCRIPTION
NO. NO.
QTY.
[MAIN UNIT] for IC-F4/S
