S.=Surface mount
6 - 4
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
C287 4030016930 S.CER ECJ0EB1A104K B 24.7/30.8
C288 4030016930 S.CER ECJ0EB1A104K
Except [USA-02], [EUR-02], [GEN-02] B 20.3/31.3
C289 4030016930 S.CER ECJ0EB1A104K
Except [USA-02], [EUR-02], [GEN-02] B 19.3/32.6
C290 4030016930 S.CER ECJ0EB1A104K T 25.9/28.6
C291 4030017460 S.CER ECJ0EB1E102K B 54.4/15.7
C292 4030017460 S.CER ECJ0EB1E102K B 74.6/20.1
C293 4030017460 S.CER ECJ0EB1E102K T 78.6/24.9
C294 4030017460 S.CER ECJ0EB1E102K B 4.7/26.2
C295 4030017460 S.CER ECJ0EB1E102K T 70.7/25.9
C296 4030017460 S.CER ECJ0EB1E102K T 76.5/24.9
C297 4030017460 S.CER ECJ0EB1E102K T 77.4/23.9
C298 4030017460 S.CER ECJ0EB1E102K T 2.8/31.8
C299 4030017460 S.CER ECJ0EB1E102K T 2.8/32.8
C300 4030017460 S.CER ECJ0EB1E102K T 2.8/33.8
C301 4030017460 S.CER ECJ0EB1E102K T 2.8/30.5
C302 4030007090 S.CER C1608 CH 1H 470J-T B 68.2/15.1
C303 4030016930 S.CER ECJ0EB1A104K T 21.9/37.9
C304 4030016930 S.CER ECJ0EB1A104K
Except [USA-02], [EUR-02], [GEN-02] T 16.7/37.2
C305 4030017420 S.CER ECJ0EC1H470J B 53.5/41.5
C306 4030017460 S.CER ECJ0EB1E102K T 31/37.6
C307 4030016930 S.CER ECJ0EB1A104K T 76/27.7
C308 4030017530 S.CER ECJ0EC1H0R5B B 57.4/12
J1 6510023520 S.CNR 54104-3692 T 7.4/25.2
F1 5210000830 S.FUS ERBFE3R00U
Except [USA-88], [EUR-88] T 76/26.2
F1 5210000900 S.FUS 0434003.NRP
[USA-88], [EUR-88] T 76/26.2
S1 2260002750 S.SW EVQP7M01K T 81.2/24
EP1 6910015370 S.BEA ACZ1005Y-102-T T 45.7/23
EP2 6910012350 S.BEA MMZ1608Y 102BT T 66.4/24.6
EP3 6910015370 S.BEA ACZ1005Y-102-T B 25.4/34.4
EP4 6910015600 S.BEA ACZ1005Y-241 (240
Ω
) T 24.2/16.7
EP5 6910015600 S.BEA ACZ1005Y-241 (240
Ω
) T 13.5/20
EP6 6910015370 S.BEA ACZ1005Y-102-T B 28/29.4
[FRONT UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
IC401 1140011780 S.IC HD6432264F01TF
Except [USA-02], [USA-02], [EUR-02], [GEN-02] T 22.9/28
IC403 1110005340 S.IC NJM12902V-TE1 T 19.2/43.2
IC405 1110001810 S.IC TA7368F (ER) T 25.9/53.3
IC406 1130011740 S.IC TC7W66FK (TE85L) T 7.2/42.3
IC407 1110005330 S.IC NJM12904V-TE1 T 7.1/31.3
IC408 1110006260 S.IC BD5242G-TR T 30.4/18.5
IC409 1130011580 S.IC 24LC64T-I/SN T 8.8/17.8
IC410 1130007570 S.IC BU4094BCFV-E2 T 40.6/37.3
Q401 1520000450 S.TR 2SB1132 T100 Q T 35.1/44.8
Q402 1590001190 S.TR XP6501-(TX) AB T 34.2/40.7
Q403 1530002840 S.TR 2SC4116-Y (TE85R) B 10.8/57
Q404 1560001330 S.FET RSR025N03 B 11.6/59.9
Q405 1560001330 S.FET RSR025N03 B 15.1/59.9
Q406 1590000430 S.TR DTC144EUA T106 B 15.6/57
Q407 1590000720 S.TR DTA144EUA T106 T 42.6/30.6
Q408 1590000430 S.TR DTC144EUA T106 T 26.5/39.1
Q409 1590002370 S.TR XP4111 (TX) T 39.8/30.8
Q411 1590001660 S.TR XP4312 (TX) T 27.4/18.6
Q412 1590000720 S.TR DTA144EUA T106 T 13/17.6
Q413 1560001330 S.FET RSR025N03 B 32.3/53
D401 1790001250 S.DIO MA2S111-(TX) T 15.9/17.2
D402 1790001250 S.DIO MA2S111-(TX) T 17.8/17.4
D403 1790001250 S.DIO MA2S111-(TX) T 13.1/15.7
D404 1790001260 S.DIO MA2S077-(TX) T 34.7/18.6
D406 1790001250 S.DIO MA2S111-(TX) T 36.5/36.9
X401 6050011720 S.XTL CR-764 (19.6608 MHz) T 42.1/18.8
R401 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
)
[EUR-88] only T 9/43.2
R402 7030005060 S.RES ERJ2GEJ 333 X (33 k
Ω
) T 11.6/51.8
[FRONT UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R403 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 16/18.4
R404 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 19/19.6
R405 7030007340 S.RES ERJ2GEJ 153 X (15 k
Ω
) T 6/36.6
R406 7030005210 S.RES ERJ2GEJ 822 X (8.2 k
Ω
) T 6/37.6
R407 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) T 6.5/26.3
R408 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 6/35.6
R409 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 16/19.4
R410 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 9.4/38.8
R411 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 11.3/24.3
R412 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 28/14.2
R413 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) T 26/14.2
R414 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) T 33.9/14.3
R415 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 37.9/23
R416 7030005100 S.RES ERJ2GEJ 154 X (150 k
Ω
) T 31.2/21
R417 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 16/14.9
R418 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) T 5/15
R420 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) T 28.8/37.7
R421 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 30.1/38
R422 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 30/37
R423 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 31.7/37
R426 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) T 14.7/37.7
R427 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 16/39.9
R428 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 16/38.9
R429 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 13.7/38.1
R430 7030007350 S.RES ERJ2GEJ 393 X (39 k
Ω
) T 12.7/40.6
R432 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) T 13.7/40.6
R433 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 11.7/40.6
R434 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 35/56.5
R435 7030007260 S.RES ERJ2GEJ 330 X (33
Ω
) T 22.6/56.2
R436 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 24.4/49.8
R437 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 31.7/41.4
R438 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 31.7/39.4
R439 7030009140 S.RES ERJ2GEJ 272 X (2.7 k
Ω
) T 34.6/38.9
R440 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 42.8/32.7
R441 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 37.3/35.5
R442 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 12.7/57.3
R443 7030005170 S.RES ERJ2GEJ 474 X (470 k
Ω
) B 11.4/55.2
R444 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 13.7/57.3
R445 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) B 32.3/55.2
R446 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) B 30.1/52.1
R455 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) T 43.2/27.8
R456 7030004980 S.RES ERJ2GEJ 101 X (100
Ω
) T 43.2/28.8
R457 7030005000 S.RES ERJ2GEJ 471 X (470
Ω
) B 45.2/48.4
R458 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 43.9/49.9
R461 7030008300 S.RES ERJ2GEJ 184 X (180 k
Ω
) T 33.1/33.6
R462 7030005720 S.RES ERJ2GEJ 563 X (56 k
Ω
) T 32.1/33.6
R463 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 31.1/33.6
R464 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 32.1/35.2
R465 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 31.1/35.2
R466 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 26.6/41.4
R467 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 25.6/41.4
R468 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 23.6/41.4
R469 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
Ω
) T 18.9/39
R470 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 20.1/38.7
R471 7030005110 S.RES ERJ2GEJ 224 X (220 k
Ω
) T 34.6/24.3
R472 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 33.6/24.3
R473 7030005240 S.RES ERJ2GEJ 473 X (47 k
Ω
) T 32.6/24.3
R474 7030005220 S.RES ERJ2GEJ 223 X (22 k
Ω
) T 31.6/24.3
R475 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 35.6/24.3
R476 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 27.2/45.2
R477 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 25.2/45.2
R478 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 23.9/44.8
R479 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 18.6/47.9
R480 7030005070 S.RES ERJ2GEJ 683 X (68 k
Ω
) T 17/46.9
R482 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 37.2/34.1
R483 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 16/21.4
R484 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 16/20.4
R485 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 11.1/22.7
R486 7410001130 S.ARY EXB28V102JX T 13.6/24.7
R487 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 33.5/23
R488 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 31.9/31.3
R489 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 32.9/31.3
R490 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 33.9/31.3
R491 7030005530 S.RES ERJ2GEJ 100 X (10
Ω
) T 37.3/17.5
R492 7030005160 S.RES ERJ2GEJ 105 X (1 M
Ω
) T 37.3/18.5
R493 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) T 35.9/18.8
R494 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) T 33.6/18.3
R495 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) T 36.9/20.8
R496 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 8/23
R497 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 11.3/25.3
R500 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 28.7/20.6
R501 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 29.3/16
R502 7030010080 S.RES ERJ2RHD 104 X (100 k
Ω
) T 36.9/14.3
R503 7030010080 S.RES ERJ2RHD 104 X (100 k
Ω
) T 38.9/14.3
R506 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) T 8.8/25.5
R507 7030005600 S.RES ERJ2GEJ 273 X (27 k
Ω
) T 7.8/25.5
R508 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
Ω
) T 5.3/22
R509 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 25.1/18
R511 7030005700 S.RES ERJ2GEJ 274 X (270 k
Ω
) T 7.8/35.6
R512 7030005090 S.RES ERJ2GEJ 104 X (100 k
Ω
) T 5.2/25.8
R513 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
) T 5.4/39.8
R514 7030010040 S.RES ERJ2GE-JPW T 7.4/48.6
C401 4030017460 S.CER ECJ0EB1E102K T 10.6/51.8
