Icom IC-F50 Service Manual Addendum

Feb. 2008
5
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C273 4030016930 S.CER ECJ0EB1A104K
[USA-88], [USA-98] only B 16.2/37.1
C274 4030016930 S.CER ECJ0EB1A104K [Scrambler] only B 17.6/26.7
C275 4030017490 S.CER C1608 JB 1A 105K-T
[Scrambler] only B 6.9/41.6
C276 4030017490 S.CER C1608 JB 1A 105K-T
[Scrambler] only B 11.1/41.6
C277 4030017490 S.CER C1608 JB 1A 105K-T
[Scrambler] only B 14.2/39.9
C279 4030017650 S.CER ECJ0EC1H270J [Scrambler] only B 29.1/41.4
C280 4030017650 S.CER ECJ0EC1H270J [Scrambler] only B 16.5/41.4
C281 4030016930 S.CER ECJ0EB1A104K T 13.6/34.5
C287 4030016930 S.CER ECJ0EB1A104K B 24.7/30.8
C288 4030016930 S.CER ECJ0EB1A104K [Scrambler] only B 20.3/31.3
C289 4030016930 S.CER ECJ0EB1A104K [Scrambler] only B 19.3/32.6
C290 4030016930 S.CER ECJ0EB1A104K T 25.9/28.6
C291 4030017460 S.CER ECJ0EB1E102K B 54.4/15.7
C292 4030017460 S.CER ECJ0EB1E102K B 74.6/20.1
C293 4030017460 S.CER ECJ0EB1E102K T 78.6/24.9
C294 4030017460 S.CER ECJ0EB1E102K B 4.7/26.2
C295 4030017460 S.CER ECJ0EB1E102K T 70.7/25.9
C296 4030017460 S.CER ECJ0EB1E102K T 76.5/24.9
C297 4030017460 S.CER ECJ0EB1E102K T 77.4/23.9
C298 4030017460 S.CER ECJ0EB1E102K T 2.8/31.8
C299 4030017460 S.CER ECJ0EB1E102K T 2.8/32.8
C300 4030017460 S.CER ECJ0EB1E102K T 2.8/33.8
C301 4030017460 S.CER ECJ0EB1E102K T 2.8/30.5
C302 4030007090 S.CER C1608 CH 1H 470J-T B 68.2/15.1
C303 4030016930 S.CER ECJ0EB1A104K T 21.9/37.9
C304 4030016930 S.CER ECJ0EB1A104K [Scrambler] only T 16.7/37.2
C305 4030017420 S.CER ECJ0EC1H470J B 53.5/41.5
C306 4030017460 S.CER ECJ0EB1E102K T 31/37.6
C307 4030016930 S.CER ECJ0EB1A104K T 76/27.7
C308 4030017530 S.CER ECJ0EC1H0R5B B 57.4/12
J1 6510023521 S.CNR 54104-3696 (3692) T 7.4/25.2
F1 5210000830 S.FUS ERBFE3R00U
except [USA-88], [USA-98] T 76/26.2
5210000901 S.FUS 0467003.NR (0434003)
[USA-88], [USA-98] T 76/26.2
S1 2260002750 S.SW EVQP7M01K T 81.2/24
EP1 6910015370 S.BEA ACZ1005Y-102-T T 45.7/23
EP2 6910012350 S.BEA MMZ1608Y 102BT T 66.4/24.6
EP3 6910015370 S.BEA ACZ1005Y-102-T B 25.4/34.4
EP4 6910015600 S.BEA ACZ1005Y-241 (240) T 24.2/16.7
EP5 6910015600 S.BEA ACZ1005Y-241 (240) T 13.5/20
EP6 6910015370 S.BEA ACZ1005Y-102-T B 28/29.4
S.=Surface mount
[VR UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
R601 7210003130 VAR TP76N97N-13F-10KA-2497
W601 8900012340 CBL OPC-1260
[CONNECT UNIT]
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
D701 1790001810 S.VSR AVR-M1005C080MTABB B 8/2.4
D702 1790001810 S.VSR AVR-M1005C080MTABB B 8/3.4
D703 1790001810 S.VSR AVR-M1005C080MTABB B 8/4.4
D704 1790001810 S.VSR AVR-M1005C080MTABB T 9.6/6.1
D705 1790001810 S.VSR AVR-M1005C080MTABB B 9.7/18.9
R701 7410001130 S.ARY EXB28V102JX T 8/4.8
C701 4030017460 S.CER ECJ0EB1E102K B 9.7/9.4
C702 4030017460 S.CER ECJ0EB1E102K B 9.7/12.2
C703 4030017460 S.CER ECJ0EB1E102K B 9.7/15.3
C704 4030017460 S.CER ECJ0EB1E102K B 7.9/19.7
EP701 6910012350 S.BEA MMZ1608Y 102BT B 8.2/8.6
EP702 6910012350 S.BEA MMZ1608Y 102BT B 8.2/11.6
EP703 6910012350 S.BEA MMZ1608Y 102BT B 8.2/14.6
EP704 6910012350 S.BEA MMZ1608Y 102BT B 8.5/17.2
EP705 6910012350 S.BEA MMZ1608Y 102BT B 9.8/17.2
