6 - 6
6-4 RECEIVE ADJUSTMENT
1) Select an adjustment item using cursor or [
↑
] / [
↓
] keys of the PC’s keyboard.
2) Set or modify the adjustment value as specifi ed using [
←
] / [
→
] keys of the PC’s keyboard, then push the [ENTER] key.
ADJUSTMENT ADJUSTMENT CONDITION LOCATION VALUE
RECEIVE
SENSITIVITY
[BPF T1]
[BPF T2]
NOTE: When
“RECEIVE SENSITIVITY” is re-adjusted, “S-METER” must be re-adjusted too.
1
• Channel : 1-12
• Receiving
• Connect the SSG to the antenna connec-
tor and set as;
Frequency : 136.100 MHz
except [F5026]
: 146.100 MHz
[F5026]
Level : +20 dBµ
†
(–87 dBm)
Modulation : 1 kHz
Deviation :
±
3.5 kHz except [EUR]
±
2.8 kHz [EUR]
1) Select the item [BPF T1] then push
the [ENTER] key.
2) Select the item [BPF T2] then push
the [ENTER] key.
(Automatic
adjustment)
S-METER
[RSSI]
(S3 level)
NOTE: "RECEIVE SENSITIVITY" MUST be adjusted before "S-METER." When "RECEIVE SENSITIVITY" is re-
adjusted, "S-METER" MUST be re-adjusted too.
1
• Channel : 1-13
• Connect the SSG to the antenna connec-
tor and set as;
Frequency : 136.100 MHz
except [F5026/H]
: 146.100 MHz [F5026/H]
Level : +23 dBµ
†
(–84 dBm)
Modulation : 1 kHz
Deviation :
±
3.5 kHz except [EUR]
±
2.8 kHz [EUR]
• Receiving
Select the item [RSSI S3 Level], then
push the [ENTER] key to store the ad-
just value for S3 level.
(Automatic
adjustment)
(S1 level)
2
• Set the SSG as;
Level : –7 dBµ
†
(–114 dBm)
• Receiving
Select the item [RSSI S1 Level], then
push the [ENTER] key, to store the ad-
just value for S1 level.
SQUELCH
[SQL]
1 • Channel : 1-14
• Connect the SSG to the antenna connec-
tor and set as;
Frequency : 136.100 MHz
except [F5026/H]
: 146.100 MHz [F5026/H]
Level : –13 dBµ
†
(–120 dBm)
Modulation : 1 kHz
Deviation :
±
3.5 kHz except [EUR]
±
2.8 kHz [EUR]
• Receiving
1) Once close the squelch by increasing
[SQL] value, then decrease the value
to open the squelch.
2) Push [ENTER] key to store the value.
(Automatic
adjustment)
†
; The output level of the standard signal generator (SSG) is indicated as the SSG’s open circuit.
To Next Page
