Icom IC-F5023 Service Manual

7 - 5
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN-A UNIT]
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
C478 4030017460 S.CER ECJ0EB1E102K T 72.2/37.7
C479 4030017460 S.CER ECJ0EB1E102K T 72/40.4
C480 4030017460 S.CER ECJ0EB1E102K T 73.9/40.4
C481 4030017460 S.CER ECJ0EB1E102K T 53.8/9.8
C482 4030017460 S.CER ECJ0EB1E102K T 101.9/22.2
C484 4030019120 S.CER GRM188B31E105KA75D T 115.8/49.5
J1 6510026770 S.CON AXK540147YG T 23/8.3
J2 6510022472 S.CON 40FLT-SM2-TB(LF)(SN)(M) T 67.5/10.6
J4 6450000140 CON HSJ0807-01-010
J6 6510022891 S.CON B13B-ZR-SM4-TF(LF)(SN) T 120/17.2
J7 6510014961 S.CON B2B-ZR-SM4-TF(LF)(SN) T 130.5/27.3
S1 2260003180 S.SWI MINISMDC050F-2 CN T 114.1/33.8
W1 7120000470 JUM ERDS2T0
W2 8900011863 CAB OPC-1195C <TJM>!
EP1 6910018460 S.BEA MMZ1005Y102C-T B 106.3/34.8
EP2 6910011560 BEA HF70BB4.5X5X1.6 [USA-01]
6910011560 BEA HF70BB4.5X5X1.6 [EXP-02]
6910011560 BEA HF70BB4.5X5X1.6 [CHN-01]
EP3 6910011560 BEA HF70BB4.5X5X1.6 [USA-01]
6910011560 BEA HF70BB4.5X5X1.6 [EXP-02]
6910011560 BEA HF70BB4.5X5X1.6 [CHN-01]
EP4 6910010280 BEA HF70BB9.5X10.4X4.9
EP5 6910010280 BEA HF70BB9.5X10.4X4.9
EP7 6910018460 S.BEA MMZ1005Y102C-T B 84.7/24.8
EP8 6910018460 S.BEA MMZ1005Y102C-T T 84.1/28.7
EP9 6910018460 S.BEA MMZ1005Y102C-T T 103.1/21.8
MP1 8510019340 S.CAS 3179 VCO CASE Y1142 B 99.2/27.3
S.=Surface mount
[FRONT UNIT]
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
IC1 1140015150 S.IC HD64F2238BTF13V (FX-3179A) B 67.8/23
IC2 1110005771 S.IC S-80942CNMC-G9CT2G B 89.1/19.3
IC3 1130012430 S.IC S-24CS64A0I-T8T1G B 90.2/15.7
IC5 1110005340 S.IC NJM12902V-TE1-#ZZZB B 25.5/23.3
IC6 1130009090 S.IC LC75834W-TLM-E B 43/21.2
Q1 1530002851 S.TRA 2SC4116-BL(TE85R,F) B 33.6/16.2
Q2 1590001050 S.TRA DTC114TUA T106 B 33.7/19.8
Q3 1590000430 S.TRA DTC144EUA T106 B 35/27
Q5 1590001050 S.TRA DTC114TUA T106 B 33.7/22.3
D1 1790000951 S.ZEN MAZ8056GML T 13.4/17.1
D2 1790000951 S.ZEN MAZ8056GML T 5.2/17.1
D3 1790000951 S.ZEN MAZ8056GML B 18.1/12.3
D5 1790001251 S.DIO MA2S1110GL B 61.6/15.7
D6 1790001261 S.DIO MA2S077G0L B 78/13.8
X1 6050011830 S.XTA CR-774 SMD-49TB 12.288 MHz B 82.3/16.5
L1 6200003640 S.COI MLF1608E 100K-T B 11.6/17.1
L2 6200001981 S.COI NLV25T-1R0J B 59.5/9.7
R7 7030009160 S.RES ERJ2GEJ 181 X (180) B 35.7/16.2
R8 7030009160 S.RES ERJ2GEJ 181 X (180) B 36.6/16.2
R9 7030005000 S.RES ERJ2GEJ 471 X (470) B 37.5/16.2
R11 7030009280 S.RES ERJ2GEJ 391 X B 33.1/18
R12 7030009140 S.RES ERJ2GEJ 272 X (2.7K) B 34.7/18
R14 7210003330 VAR RK09D1130A1N
R15 7030005120 S.RES ERJ2GEJ 102 X (1K) B 7.2/17.1
R16 7030005120 S.RES ERJ2GEJ 102 X (1K) B 16.5/13.2
R18 7030005090 S.RES ERJ2GEJ 104 X (100K) T 8.2/17.1
R19 7030005090 S.RES ERJ2GEJ 104 X (100K) B 19.7/13.2
R20 7030008300 S.RES ERJ2GEJ 184 X (180K) B 61.3/29.9
R21 7030005720 S.RES ERJ2GEJ 563 X (56K) B 61.3/30.8
R22 7030005220 S.RES ERJ2GEJ 223 X (22K) B 61.3/31.7
R23 7030005240 S.RES ERJ2GEJ 473 X (47K) B 30.9/27.9
R24 7030005240 S.RES ERJ2GEJ 473 X (47K) B 30.9/27
R25 7030005220 S.RES ERJ2GEJ 223 X (22K) B 32.6/28.8
R26 7030005240 S.RES ERJ2GEJ 473 X (47K) B 29.2/27
R27 7030005240 S.RES ERJ2GEJ 473 X (47K) B 26.9/27.9
R28 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 30.9/26.1
R29 7030008290 S.RES ERJ2GEJ 183 X (18K) B 32.6/27.9
R32 7030007340 S.RES ERJ2GEJ 153 X (15K) B 30.9/23.3
R33 7030005220 S.RES ERJ2GEJ 223 X (22K) B 30.9/24.2
R34 7030005060 S.RES ERJ2GEJ 333 X (33K) B 30.9/22.4
R35 7030005070 S.RES ERJ2GEJ 683 X (68K) B 30.9/21.5
R36 7030005070 S.RES ERJ2GEJ 683 X (68K) B 30.9/20.6
R37 7030005070 S.RES ERJ2GEJ 683 X (68K) B 29.2/21.5
R38 7030005070 S.RES ERJ2GEJ 683 X (68K) B 29.2/22.4
R39 7030005070 S.RES ERJ2GEJ 683 X (68K) B 29.2/23.3
R40 7030005240 S.RES ERJ2GEJ 473 X (47K) B 20.1/26.1
R41 7030005600 S.RES ERJ2GEJ 273 X (27K) B 20.1/27.9
R42 7030005240 S.RES ERJ2GEJ 473 X (47K) B 23.6/27.9
R43 7030007350 S.RES ERJ2GEJ 393 X (39K) B 25.2/27.9
R44 7030005100 S.RES ERJ2GEJ 154 X (150K) B 21.8/27
R45 7030005160 S.RES ERJ2GEJ 105 X (1M) B 23.6/28.8
R46 7030005120 S.RES ERJ2GEJ 102 X (1K) B 33.4/3.3
R47 7030009140 S.RES ERJ2GEJ 272 X (2.7K) B 33.4/5.1
R48 7030010040 S.RES ERJ2GEJ-JPW B 28/18.3
R51 7030005090 S.RES ERJ2GEJ 104 X (100K) B 59.5/15.7
R58 7030005050 S.RES ERJ2GEJ 103 X (10K) B 85.8/13.6
R60 7030005090 S.RES ERJ2GEJ 104 X (100K) B 84/8.6
R65 7030005120 S.RES ERJ2GEJ 102 X (1K) B 59.7/29.9
R68 7030005090 S.RES ERJ2GEJ 104 X (100K) B 85.8/15.2
R73 7030005050 S.RES ERJ2GEJ 103 X (10K) B 45.2/14.6
R74 7030005050 S.RES ERJ2GEJ 103 X (10K) B 47/14.6
R75 7030005050 S.RES ERJ2GEJ 103 X (10K) B 44.3/14.6
R76 7030005120 S.RES ERJ2GEJ 102 X (1K) T 10.4/17.1
R77 7030005030 S.RES ERJ2GEJ 152 X (1.5K) B 72.5/9.3
R78 7030005240 S.RES ERJ2GEJ 473 X (47K) B 42.2/14.3
R82 7030005090 S.RES ERJ2GEJ 104 X (100K) B 39/14.6
R83 7030005090 S.RES ERJ2GEJ 104 X (100K) B 40.8/14.6
R84 7030005090 S.RES ERJ2GEJ 104 X (100K) B 39.9/14.6
R90 7030006610 S.RES ERJ2GEJ 394 X (390K) B 53.8/4.1
R101 7030008010 S.RES ERJ2GEJ 123 X (12K) B 77.4/14.9
R102 7030008010 S.RES ERJ2GEJ 123 X (12K) B 77.4/12.7
R103 7030008010 S.RES ERJ2GEJ 123 X (12K) B 78.8/12.2
R104 7030005090 S.RES ERJ2GEJ 104 X (100K) B 75.7/14.9
R105 7030005530 S.RES ERJ2GEJ 100 X (10) B 77.4/15.8
R106 7030005160 S.RES ERJ2GEJ 105 X (1M) B 78.8/17.2
R107 7030005050 S.RES ERJ2GEJ 103 X (10K) B 86.7/18.5
R108 7030005120 S.RES ERJ2GEJ 102 X (1K) B 74/29.4
R109 7030005120 S.RES ERJ2GEJ 102 X (1K) B 72.6/30.9
R110 7030010040 S.RES ERJ2GEJ-JPW B 59.7/27.7
R111 7030005120 S.RES ERJ2GEJ 102 X (1K) B 57.5/22.2
R112 7030005120 S.RES ERJ2GEJ 102 X (1K) B 57.5/23.2
R113 7030005090 S.RES ERJ2GEJ 104 X (100K) B 75.7/15.8
R114 7030005090 S.RES ERJ2GEJ 104 X (100K) B 78/25.8
R115 7410001130 S.ARR EXB28V102JX B 57.5/25.2
R116 7030005120 S.RES ERJ2GEJ 102 X (1K) B 60.6/17.3
R117 7030005120 S.RES ERJ2GEJ 102 X (1K) B 71/12.7
R118 7030005120 S.RES ERJ2GEJ 102 X (1K) B 71.9/14.6
R119 7030005120 S.RES ERJ2GEJ 102 X (1K) B 73.5/14.9
R120 7030005120 S.RES ERJ2GEJ 102 X (1K) B 75.7/30.3
R121 7030005120 S.RES ERJ2GEJ 102 X (1K) B 72.9/31.8
R122 7030005120 S.RES ERJ2GEJ 102 X (1K) B 71.3/32.2
R123 7030005090 S.RES ERJ2GEJ 104 X (100K) B 58.9/17.3
R124 7030005120 S.RES ERJ2GEJ 102 X (1K) B 58.9/18.2
R125 7030005120 S.RES ERJ2GEJ 102 X (1K) B 58.9/19.1
