REMOTE CONTROL OPERATION
1
1-6 OPERATION EXAMPLE FOR PHONE PATCH
DD
Description
Phone Patch function allows communication to a
transceiver from a telephone line, or connection to a
telephone line from a transceiver. During the Phone
Patch operation, the voice communication is sim-
plex. (The mute control is activated from the trans-
ceiver’s continuous tone SQL.)
■ Operation from the transceiver
One of two methods (Dial and Auto-dial) of telephone
access is selectable from the transceiver.
Dial: Direct dialing from the keypad of a transceiver.
Auto-dial: Using the pre-programmed phone No. (up
to 20 channels are stored) in the repeater.
DD
TEL Dial (0015 Default)
q Enter the programmed password from transceiv-
er.
Code:
∗
0001#
• Verify the repeater replies “System Password OK
ACK (1111).”
• If the repeater replies “NG ACK (4040),” make sure
the password, header tone and de-limiter tone are
correct, and try again.
w Enter the “TEL Dial” command within 10 sec.
Code:
∗
0015#
• Verify the repeater replies “OK ACK (3333).”
• If the 10 sec. input standby time runs out, enter the
password and command continuously (Code:
∗
0001#0015#).
e Enter the telephone number (if the number is 060-
3355-2244) as sub code within 10 sec.
Code:
∗
06033552244#
• Verify the repeater replies “OK ACK (3333).”
• If the 10 sec. input standby time runs out, enter the
password and command continuously (Code:
∗
0001#0015#06033552244#).
• The repeater starts calling the number.
r When the connection has been confirmed, talk to
the phone by simplex voice communication.
t After conversation is finished enter the password
followed by the “System Control Exit” command to
terminate Phone Patch operation.
Code:
∗
0001
#
0002#
• Verify the repeater replies “System Control Exit ACK
(2020),” then repeater hangs on the phone.
DD
TEL Autodial (0016 Default)
Autodial number: 12 (Channel 12)
q Enter the following DTMF codes.
Code:
∗
0001#0016#12#
• Verify the repeater replies “OK ACK (3333).”
• If the repeater replies “NG ACK (4040),” make sure
the password, header tone, de-limiter tone and com-
mand code are correct, and try again.
• The repeater starts calling the autodial channel 12.
w When the connection has been confirmed, talk to
the phone by simplex voice communication.
e After conversation is finished enter the password
followed by the “System Control Exit” command to
terminate Phone Patch operation.
Code:
∗
0001
#
0002#
• Verify the repeater replies “System Control Exit ACK
(2020),” then repeater hangs on the phone.
■ Operation from the phone line
DD
TX Start (0005 Default)
Step by step operation from the phone line.
q Dial the phone number of the phone line that the
repeater is connected to.
w When the connection has been confirmed, enter
the programmed password.
Code:
∗
0001#
• Verify the repeater replies “System Password OK
ACK (1111).”
• If the repeater replies “NG ACK (4040),” make sure
the password, header tone and de-limiter tone are
correct, and try again.
e Enter the “TX Start” command within 10 sec.
Code:
∗
0005#
• Verify the repeater replies “OK ACK (3333).”
• If the 10 sec. input standby time runs out, enter the
password and command continuously (Code:
∗
0001#0005#).
• The repeater starts the downlink transmission for
Phone Patch operation.
r After conversation is finished, hang up the phone,
the repeater automatically disconnects the phone
and stops the downlink transmission.
DD
TX Stop (0006 Default)
During Phone Patch operation this command stops
repeater from transmitting, for changing repeater settings.
q Enter the following DTMF code (password and
command code).
Code:
∗
0001#0006#
• Verify the repeater replies “OK ACK (3333).”
• If the repeater replies “NG ACK (4040),” make sure
the password, header tone, de-limiter tone and TX
stop code are correct, and try again.
w You may continue remote control operation from
the phone line to make other settings in the
repeater, or hang up the phone if there is nothing
else to change.
