Icom iF110 User Manual

■ Receiving and transmitting
RECEIVING:
q Push [ ] to turn the power ON.
w Push [ ] and [ ] to select a channel.
e When receiving a call, adjust the audio output level to a
comfortable listening level.
TRANSMITTING:
q Take the microphone off hook.
• 2-tone, 5-tone mute may be released. (The ‘audible’ condition is
selected and “ ” appears.)
• A priority channel may be selected automatically.
w Wait for the channel to become clear.
• The channel is busy when “ ” appears.
e Push the [CALL] key when initiating a call from your side.
• Coded audio may be heard from the transceiver, then “ ” ap-
pears.
• This operation may not be necessary depending on your signal-
ing system. Contact your dealer.
r While pushing and holding [PTT], speak into the micro-
phone at your normal voice level.
t Release [PTT] to receive.
IMPORTANT!: To maximize the readability of your signal;
➥ Pause briefly after pushing [PTT].
➥ Hold the microphone 5 to 10 cm (2 to 4 inches) from
your mouth, then speak into the microphone at a nor-
mal voice level.
D Transmitting notes
• Transmit inhibit function
The transceiver has several inhibit functions which restrict
transmission under the following conditions:
- The channel is in mute condition (‘Inaudible’ condition; “ ” does
not appear).
- Channel is busy.
- A matched/un-matched CTCSS code is received. (Depending on
the pre-setting.)
- The selected channel is a ‘receive only’ channel.
• Time-out timer
After continuous transmission for a pre-programmed period,
the time-out timer is activated causing the transceiver to stop
transmitting and automatically select receive.
• Penalty timer
Once the time-out timer is activated, transmission is further
inhibited for a period determined by the penalty timer.
8
2
OPERATION
