iii
FORWARD
Thank you for purchasing this Icom repeater. The
IC-FR5000/IC-FR6000 vhf/uhf fm repeaters is de-
signed and built with Icom’s state of the art technol-
ogy and craftsmanship. With proper care, this product
should provide you with years of trouble-free opera-
tion.
We want to take a couple of moments of your time
to thank you for making the IC-FR5000/IC-FR6000
your repeater of choice, and hope you agree with
Icom’s philosophy of “technology first.” Many hours
of research and development went into the design of
your IC-FR5000/IC-FR6000.
D FEATURES
m Up to 2 channels operation
You can install a channel extension module (op-
tional UR-FR5000/UR-FR6000) into a repeater. 2
channels can be operated as the repeater when a
channel extension module is installed.
m Built-in 5-Tone, DTMF encoder & decoder
Multiple signaling systems are equipped as stan-
dard. These systems are fully compatible with
Icom F-series radios.
m DTMF remote control capability
You can control the repeater from a remote loca-
tion over the air or over a phone line with DTMF.
m D-Sub 25 pin ACC port equipped
You can use the optional equipment via the D-sub
25 pin ACC port equipped on the repeater’s rear
panel.
m On-line control and Digital Trunking opera-
tion
The on-line control and digital trunking opera-
tion are available when the optional UC-FR5000
trunking/network controller is installed into a
repeater.
m Other features
- Wide frequency coverage (136 to 174 MHz, 400
to 470 MHz, 450 to 512/520 MHz)
- PC programmable
- 19 inch rack mount
- Optional Voice Scrambler Unit (UT-109R/
UT-110R) for base operating mode
SUPPLIED ACCESSORIES
The following accessories are supplied.
Handles For handles attachment
Spacers
Screws
DC power cable Function name stickers*
KEY SEAL
* Used for labelling the program-
mable function keys according
to their assinged functions.
To Next Page
