Concord CX - Installation
Key No. Description Qty. Product No.
12D Boiler body insulation ................................ CX 40 1 150 093
.................................................................. CX50/60 1 150 094
.................................................................. CX70/80 1 150 095
.................................................................. CX90/100 1 150 096
23 Centre main burner ................................... Worgas 0.087.751 CX 40 1 150 153
.................................................................. Worgas 0.087.753 CX 50 / 60 1 150 154
.................................................................. Worgas 0.087.755 CX 70 / 80 1 150 155
.................................................................. Worgas 0.087.757 CX 90 / 100 1 150 156
24 End main burners ...................................... Worgas 0.087.750 CX 40 2 150 149
.................................................................. Worgas 0.087.752 CX 50 / 60 2 150 150
.................................................................. Worgas 0.087.754 CX 70 / 80 2 150 151
.................................................................. Worgas 0.087.756 CX 90 / 100 2 150 152
26 Main burner injectors ................................. Size 3.4 mm; CX 40 3 111 323
.................................................................. Size 3.82mm; CX 50 3 111 324
.................................................................. Size 4.12mm; CX 60 3 111 325
.................................................................. Size 4.57mm; CX 70 3 111 326
.................................................................. Size 4.86mm; CX 80 3 013 177
.................................................................. Size 5.2mm; CX 90 3 111 328
.................................................................. Size 5.3mm; CX 100 3 013 179
27 Pilot burner - HONEYWELL Q 349 A1067 complete with 56 /42A injector 1 077 105
28 Pilot burner injector - HONEYWELL 56 / 42A 1 004 545
29 Gas control valve - HONEYWELL V4600C 1391
1/2 in. CX40/60 1 111 265
. Gas control valve - HONEYWELL V4400C 1369
3/4 in. Softlite (white button)
CX70/100 1 111 757
30 Spark generator (less bracket) - VERNITRON 60080/002 1 003 939
32 Ignition electrode and H.T. lead assembly - VERNITRON 1 130 947
33 Thermocouple- HONEYWELL Q 309 A-2762, 1200mm long 1 002 937
34 Thermocouple interrupter lead assembly (thermocouple to overheat 'stat.) 1 132 009
35 Thermocouple interrupter lead assembly (overheat 'stat. to gas valve) 1 135 944
37 Electronic thermostat sensor assembly - PACTROL, 2450 mm long 1 013 459
38 Thermostat potentiometer assembly 1 111 809
39 Thermostat knob 1 013 241
40 Overheat thermostat / bracket assembly - RAK 77.4/3836 1 170689
41 Control box assembly, complete with the front panel and back panel
assemblies plus printed circuit boards 'No.1C' and 'No.6A', fascia panel,
and the control knob. 1 112 092
42 Printed circuit board 'No.1C' 1 060 562
43 Printed circuit board 'No. 6A' 1 060 554
SHORT LIST OF PARTS
When ordering spare parts please quote:
1. Boiler model
2. Boiler serial no. (refer to the data plate on the combustion chamber)
3. Boiler B.G. P.I. No. (refer to the data plate on the combustion chamber)
4. Description
5. Quantity
6. Product no.
The following are parts commonly
required as replacements, due to damage
or expendability.
Their failure or absence is likely to affect
the safety and/or performance of this
appliance.
