Concord CXA/H - Installation and Servicing
SHORT LIST OF PARTS
Key No. Description Qty. Product No.
12.4 Boiler body insulation ............................... CXA 40/H 1 150 093
.................................................................. CXA 50/60/H 1 150 094
.................................................................. CXA 70/80/H 1 150 095
.................................................................. CXA 90/100/H 1 150 096
.................................................................. CXA 110/120/H 1 154 856
23 LH main burner ......................................... Worgas 0.087.751 CXA 40/H 1 150 153
.................................................................. Worgas 0.087.753 CXA 50/60/H 1 150 154
.................................................................. Worgas 0.087.755 CXA 70/80/H 1 150 155
.................................................................. Worgas 0.087.757 CXA 90/100/H 1 150 156
.................................................................. Worgas 0.087.761 CXA 110/120/H 1 154 812
24 Centre & RH main burners ....................... Worgas 0.087.750 CXA 40/H 2 150 149
.................................................................. Worgas 0.087.752 CXA 50/60/H 2 150 150
.................................................................. Worgas 0.087.754 CXA 70/80/H 2 150 151
.................................................................. Worgas 0.087.756 CXA 90/100/H 2 150 152
.................................................................. Worgas 0.087.760 CXA 110/120/H 2 154 811
26 Main burner injectors ................................ Size 3.4 mm; CXA 40/H 3 111 323
.................................................................. Size 3.82mm; CXA 50/H 3 111 324
.................................................................. Size 4.12mm; CXA 60/H 3 111 325
.................................................................. Size 4.57mm; CXA 70/H 3 111 326
.................................................................. Size 4.86mm; CXA 80/H 3 013 177
.................................................................. Size 5.2mm; CXA 90/H 3 111 328
.................................................................. Size 5.3mm; CXA 100/H 3 013 179
.................................................................. Size 5.5mm; CXA 110/H 3 157 904
.................................................................. Size 5.6mm; CXA 120/H 3 154 840
27 Pilot burner - HONEYWELL Q 349 A1067 complete with injector 1 077 105
28 Pilot burner injector - HONEYWELL 45900421-011 1 004 545
29 Gas control valve - HONEYWELL V4601 AB 1034 1 154 810
. Gas control valve - HONEYWELL VR4605 AB 1019 CXA 90 - 120/H 1 111 869
Gas valve plugs and lead assy. CXA 40 -120/H 1 154 733
Gas valve plugs and lead assy. CXA 90 -120/H 1 112 431
Gas valve plugs and lead assy. CXA 90 -120/H 1 139 269
32 Ignition electrode and H.T. lead assy. ...... 1 154 967
33 Flame sensing electrode ......................... 1 154 818
Boiler status neons .................................. Burner on 1 154 854
.................................................................. Overheat 1 154 855
.................................................................. Lockout 1 154 855
37 Electronic thermostat sensor & lead assembly 1 154 816
38 Thermostat potentiometer assembly ....... 1 154 850
39 Thermostat knob ....................................... 1 170 859
40 Overheat thermostat ................................. 1 155 791
41 Control box assembly, complete .............. 1 157 152
42 Printed circuit board S4561B1054 ........... 1 154 813
43 Printed circuit board W4115A1020 .......... 1 154 815
When ordering spare parts please quote:
1. Boiler model
2. Boiler serial no. (refer to the data plate on the combustion chamber)
3. Boiler B.G. P.I. No. (refer to the data plate on the combustion chamber)
4. Description
5. Quantity
6. Product no.
The following are parts commonly
required as replacements, due to
damage or expendability.
Their failure or absence is likely to affect
the safety and/or performance of this
appliance.
