SHORT LIST OF PARTS
Esprit - Installation and Servicing
Ecl 1598
97
CONTROLS ASSEMBLY
98
BURNER ASSEMBLY
8. Burner assembly with screws and gasket.
67
66
25
69
68
70
27
28
38
64
26
65
Esp8894
25. User Control PCB
26. PCB Primary Control
27. Mains Switch
28. Pre-heat and Winter/Summer Switch
38. Pressure Gauge
65. Control Box Lid
66. Mains Cover
67. Controls Cover
68. Potentiometer Knob
69. Control Box Clip
70. Programmer Insert
