IKEA LIVSLAGA User Manual

ENGLISH 11
Injector table
Type of gas used Type of burner Injector
marking
Rated thermal
ow rate kW
Rated
consumption
Reduced heat
capacity kW
Gas pressure (mbar)
min. rat. max.
HU
NATURAL GAS
(Methane)
G20
powerburner
semi-rapid
auxiliary
130 T2 A
101 Z
72 X
3,50
2,00
1,00
333 l/h
190 l/h
95 l/h
2,35
0,40
0,40
20 25 33
NATURAL GAS
G25.1
powerburner
semi-rapid
auxiliary
142 B
Y 103
F1 74
3,50
2,00
1,00
387 l/h
221 l/h
111 l/h
2,20
0,35
0,35
18 25 33
LIQUEFIED
PETROLEUMGAS
(Butane) G30
(Propane) G31
powerburner
semi-rapid
auxiliary
93T4P
69
50
3,50
2,00
1,00
254 g/h
145 g/h
73 g/h
1,90
0,35
0,30
25 30 35
PL
NATURAL GAS
(Methane)
G20
powerburner
semi-rapid
auxiliary
138 T2 A
101 Z
72 X
3,50
2,00
1,00
333 l/h
190 l/h
95 l/h
2,20
0,35
0,30
17 20 25
NATURAL GAS
G2.350
powerburner
semi-rapid
auxiliary
190 T2
128 Y
95 Y
3,50
2,00
1,00
463 l/h
264 l/h
132 l/h
1,80
0,35
0,30
10 13 16
NATURAL GAS
G27
powerburner
semi-rapid
auxiliary
155
Y 103
F1 77
3,50
2,00
1,00
406 l/h
232 l/h
116 l/h
2,20
0,35
0,30
16 20 23
LIQUEFIED
PETROLEUMGAS
(Butane) G30
(Propane) G31
powerburner
semi-rapid
auxiliary
93T4P
69
50
3,50
2,00
1,00
254 g/h
145 g/h
73 g/h
2,00
0,45
0,35
25 37 45
Category II2ELwLs3B/P (PL) II2HS3B/P (HU)
Type of gas used Model conguration
4 BURNERS
Rated thermal
owrate (kW)
Total rated
consumption
Air required (m
3
) for
burning1m
3
of gas
HU
G20
25 mbar
1PB-2SR
1 AUX
8,50 808 l/h 9,52
G25.1
25 mbar
1PB-2SR
1 AUX
8,50 940 l/h 8,187
G30/G31
30 mbar
1PB-2SR
1 AUX
8,50 617 g/h 30,94
PL
G20
20 mbar
1PB-2SR
1 AUX
8,50 809 l/h 9,52
G2.350
13 mbar
1PB-2SR
1 AUX
8,50 1123 l/h 30,94
G27
20 mbar
1PB-2SR
1 AUX
8,50 986 l/h 30,94
G30/G31
37 mbar
1PB-2SR
1 AUX
8,50 617 g/h 23,80
Electric Power: 220 - 240 V ~ 50/60 Hz
If the appliance is intended to be in use in Hungary, injectors already assembled (G20 - 20mbar) must
bereplacedaccordingtoHungarianmarketregluation,availableinInstructionforUser.
Injectorsforreplacementareavailableinthekit.PleaserefertoUserManualinformation.
Injectorreplacementmustbedonebyaqualiedtechnician.
