13
ENGLISH
Power limitation
When rst connecting to the domestic power supply, the installer must set the power of the hob
cooking areas based on the actual abilities and capacity of the power supply itself.
If this is not necessary, the hob can be turned on directly using , otherwise, follow the
operations below to access the menu.
- Connect the hob to the domestic mains power.
- All the digits light up for a few seconds.
- As soon as the digits go out, press the hob selection buttons and hold for 5
seconds until the current setting appears in the timer digits.
- Use “ + “ and “ - “ to select a suitable power absorption, following the table provided below.
- Press the hob selection buttons again and hold them for 5 seconds to conrm selection.
Table of value..:
Conguration Kw Notes
0 3.7 Kw Standard initial setting
1 3.5 Kw
2 3 Kw
3 2.5 Kw
4 2 Kw
5 1.5 Kw
