Installation
Installation process must follow the laws,
ordinances, directives and standards
(electrical safety rules and regulations,
proper recycling in accordance with the
regulations, etc.) in force in the country
of use!
• For further information on the
installation refer to the Assembly
Instruction.
• Do not use silicon sealant between the
appliance and the worktop.
• Make sure that the space underneath
the hob is sufficient for air circulation.
Please refer to the Assembly
Instruction.
• The bottom of the appliance can get
hot. If the appliance is installed above
the drawers, make sure to install a
non-combustible separation panel
under the appliance to prevent access
to the bottom. Please refer to the
Assembly Instruction.
• Ventilation of the appliance must
comply with the manufacturer’s
instructions.
• Create a front opening of at least 28
cm2 in the unit into which the hob is
to be fitted, to allow aeration of the
product.
Requirements for kitchen units
• If the appliance is mounted on
ammable materials, the guidelines
and regulations relating to low voltage
installations and re prevention must
be followed strictly.
• For the tted units, the components
(plastic materials and veneered wood)
must be mounted with heat-resistant
adhesives (min. 85° C): the use of
unsuitable material and adhesives may
result in warping and detachment.
• The use of decorative hardwood
borders around the worktop behind
the appliance is allowed, provided the
minimum distance always complies
with the indications provided in the
installation drawings.
Min.
28 mm
min.
100 mm
55 mm
490
+2
mm
520 mm
290 mm
min.
500 mm
Min.
28 mm
max.
R 5 mm
270
+2
mm
• For further information on the
installation refer to the Assembly
Instruction
• If there is no oven beneath the hob,
install a separation panel under the
appliance according to the Assembly
Instruction.
