Infinity Reference 310a Service Manual

PART NO NOMENCATURE DESCRIPTION MFR PARTS REF NO Q'TY
TRS-00-00087 TRANSISTOR SMALL SIGNAL PNP KTA1023Y Q01,144,244 3
TRS-00-00088 TRANSISTOR SMALL SIGNAL NPN KTC1027Y Q134,234 2
TRS-00-00091 TRANSISTOR SMALL SIGNAL PNP KTA1268GR Q22 1
TRS-00-00111 TRANSISTOR SMALL SIGNAL NPN KTC3200GR Q151,251 2
TRS-00-00090 TRANSISTOR SMALL SIGNAL PNP KTA1266GR Q11,12,23,33,133,141,142,233,241,242 10
TRS-00-00110 TRANSISTOR SMALL SIGNAL NPN KTC3198GR Q02,90,131,132,143,181,231,232,243,281 10
TRS-00-00109 TRANSISTOR SMALL SIGNAL NPN KTC3198BL Q21 1
DIO-00-00108 DIODE FAST RECOVERY FR154 D51,52,53,54 4
DIO-00-00003 DIODE RECTIFIER IN4004 D02 1
DIO-00-00006 DIODE SWITCHING SIGNAL 1SS133 /1N4148 D03,04,11,151,168,251,268 7
RES-00-00577 RESISTOR METAL FILM 1/5WF 750 OHM R108,208 2
RES-00-00590 RESISTOR METAL FILM 1/5WF 910 OHM R172,272 2
RES-00-00523 RESISTOR METAL FILM 1/5WF 4.7K OHM R62 1
RES-00-00545 RESISTOR METAL FILM 1/5WF 5.6K OHM R120,220 2
RES-00-00589 RESISTOR METAL FILM 1/5WF 9.4K OHM R257 1
RES-00-00402 RESISTOR METAL FILM 1/5WF 10K OHM R125,126,225,226 4
RES-00-00399 RESISTOR METAL FILM 1/5WF 10.5K OHM R60 1
RES-00-00425 RESISTOR METAL FILM 1/5WF 15K OHM R171,271 2
RES-00-00421 RESISTOR METAL FILM 1/5WF 15.2K OHM R155,255 2
RES-00-00467 RESISTOR METAL FILM 1/5WF 22K OHM R101,121,201,221 4
RES-00-00537 RESISTOR METAL FILM 1/5WF 47K OHM R102,103,105,106,202,203,205,206,256 9
RES-00-00591 RESISTOR METAL FILM 1/5WF 91K OHM R156 1
RES-00-00610 RESISTOR CARBON FILM 1/5WJ 10 OHM R15 1
RES-00-00660 RESISTOR CARBON FILM 1/5WJ 22 OHM R133,134,143,144,233,234,243,244 8
RES-00-00716 RESISTOR CARBON FILM 1/5WJ 47 OHM R43,44,53,54,136,146,236,246 8
RES-00-00615 RESISTOR CARBON FILM 1/5WJ 120 OHM R150,250 2
RES-00-00747 RESISTOR CARBON FILM 1/5WJ 750 OHM R16 1
RES-00-00633 RESISTOR CARBON FILM 1/5WJ 1K OHM R31,42,52,92,107,127,128,131,135,141 22
R145,195,196,207,227,228,231,235,241,245
R295,296
RES-00-00598 RESISTOR CARBON FILM 1/5WJ 1.5K OHM R151,251 2
RES-00-00644 RESISTOR CARBON FILM 1/5WJ 2.7K OHM R147,247 2
RES-00-00676 RESISTOR CARBON FILM 1/5WJ 3.9K OHM R12,137,237 3
RES-00-00702 RESISTOR CARBON FILM 1/5WJ 4.7K OHM R01,02,11 3
RES-00-00720 RESISTOR CARBON FILM 1/5WJ 5.6K OHM R113,115,132,142,213,215,232,242 8
RES-00-00734 RESISTOR CARBON FILM 1/5WJ 6.8K OHM R199,299 2
RES-00-00751 RESISTOR CARBON FILM 1/5WJ 8.2K OHM R05 1
RES-00-00608 RESISTOR CARBON FILM 1/5WJ 10K OHM R13,14,61,110,111,112,114,122,210,211 13
R212,214,222
RES-00-00623 RESISTOR CARBON FILM 1/5WJ 15K OHM R34,35,152,252 4
RES-00-00658 RESISTOR CARBON FILM 1/5WJ 22K OHM R32,91 2
RES-00-00663 RESISTOR CARBON FILM 1/5WJ 24K OHM R21,22 2
RES-00-00687 RESISTOR CARBON FILM 1/5WJ 33K OHM R33 1
RES-00-00697 RESISTOR CARBON FILM 1/5WJ 39K OHM R197,297 2
RES-00-00714 RESISTOR CARBON FILM 1/5WJ 47K OHM R90 1
RES-00-00730 RESISTOR CARBON FILM 1/5WJ 56K OHM R04,181,281 3
RES-00-00742 RESISTOR CARBON FILM 1/5WJ 68K OHM R25 1
RES-00-00604 RESISTOR CARBON FILM 1/5WJ 100K OHM R129,168,229,268 4
RES-00-00620 RESISTOR CARBON FILM 1/5WJ 150K OHM R198,298 2
RES-00-00664 RESISTOR CARBON FILM 1/5WJ 270K OHM R123,124,223,224 4
RES-00-00706 RESISTOR CARBON FILM 1/5WJ 430K OHM R63 1
RES-00-00053 RESISTOR METAL FILM 1/2WJ 4.7 OHM R161,261 2
RES-00-00018 RESISTOR METAL FILM 1/2WJ 10 OHM R03 1
RES-00-00038 RESISTOR METAL FILM 1/2WJ 220 OHM R41,51 2
ELC-00-00223 CAPACITOR ELECTROLYTIC "SMS" 2.2/50V C120,131,141,220,231,241 6
ELC-00-00229 CAPACITOR ELECTROLYTIC "SMS" 4.7/50V C128,228 2
ELC-00-00195 CAPACITOR ELECTROLYTIC "SMS" 10/16V C155,255,800 3
ELC-00-00203 CAPACITOR ELECTROLYTIC "SMS" 10/25V C15 1
ELC-00-00197 CAPACITOR ELECTROLYTIC "SMS" 22/16V C102,103,123,124,202,203,223,224 8
Reference 7520a/7521a
Electrical Parts List
14
