English

Appendices

RS232 Protocol Function List

Baud Rate : 9600

Data Bits: 8

Parity: None

Stop Bits: 1

Flow Control : None

UART16550 FIFO: Disable

Projector Return (Pass): P

Projector Return (Fail): F

1. There is a <CR> after

all ASCII commands.

2. 0D is the HEX code

for <CR> in ASCII

code.

XX=00-99, projector's ID,

XX=00 is for all projectors

Optoma V1 Command Table.

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

Baud Rate : 9600 Note : There is a <CR> after all ASCII commands

Data Bits: 8 0D is the HEX code for <CR> in ASCII code

Parity: None

Stop Bits: 1

Flow Control : None

UART16550 FIFO: Disable

Projector Return (Pass): P

Projector Return (Fail): F XX=01ˀ99, projector's ID, XX=00 is for all projectors

SEND to projector

232 ASCII Code HEX Code Function Description

~XX00 1 7E 30 30 30 30 20 31 0D Power ON

~XX00 0 7E 30 30 30 30 20 30 0D Power OFF (0/2 for backward compatible)

~XX00 1 ~nnnn 7E 30 30 30 30 20 31 20 a 0D Power ON with Password ~nnnn = ~0000 (a=7E 30 30 30 30) ~9999 (a=7E 39 39 39 39)

~XX01 1 7E 30 30 30 31 20 31 0D Resync

~XX02 1 7E 30 30 30 32 20 31 0D AV Mute On

~XX02 0 7E 30 30 30 32 20 30 0D Off (0/2 for backward compatible)

~XX03 1 7E 30 30 30 33 20 31 0D Mute On

~XX03 0 7E 30 30 30 33 20 30 0D Off (0/2 for backward compatible)

~XX04 1 7E 30 30 30 34 20 31 0D Freeze

~XX04 0 7E 30 30 30 34 20 30 0D Unfreeze (0/2 for backward compatible)

~XX05 1 7E 30 30 30 35 20 31 0D Zoom Plus

~XX06 1 7E 30 30 30 36 20 31 0D Zoom Minus

~XX12 1 7E 30 30 31 32 20 31 0D Direct Source Commands HDMI

~XX12 5 7E 30 30 31 32 20 35 0D VGA1

~XX12 6 7E 30 30 31 32 20 36 0D VGA 2

~XX12 8 7E 30 30 31 32 20 38 0D VGA1 Component

~XX12 9 7E 30 30 31 32 20 39 0D S-Video

~XX12 10 7E 30 30 31 32 20 31 30 0D Video

~XX12 13 7E 30 30 31 32 20 31 33 0D VGA 2 Component

~XX20 1 7E 30 30 32 30 20 31 0D Display Mode Presentation

~XX20 2 7E 30 30 32 30 20 32 0D Bright

~XX20 3 7E 30 30 32 30 20 33 0D Movie

~XX20 4 7E 30 30 32 30 20 34 0D sRGB

~XX20 5 7E 30 30 32 30 20 35 0D User

~XX20 7 7E 30 30 32 30 20 37 0D Blackboard

~XX20 9 7E 30 30 32 30 20 39 0D 3D

~XX21 n 7E 30 30 32 31 20 a 0D Brightness n = -50 (a=2D 35 30) ~ 50 (a=35 30)

~XX22 n 7E 30 30 32 32 20 a 0D Contrast n = -50 (a=2D 35 30) ~ 50 (a=35 30)

~XX23 n 7E 30 30 32 33 20 a 0D Sharpness n = 1 (a=31) ~ 15 (a=31 35)

~XX24 n 7E 30 30 32 34 20 a 0D Color Settings/White Red n = -50 (a=2D 35 30) ~ 50 (a=35 30)

~XX25 n 7E 30 30 32 35 20 a 0D Green n = -50 (a=2D 35 30) ~ 50 (a=35 30)

~XX26 n 7E 30 30 32 36 20 a 0D Blue n = -50 (a=2D 35 30) ~ 50 (a=35 30)

~XX33 1 7E 30 30 33 33 20 31 0D Reset

~XX34 n 7E 30 30 33 34 20 a 0D BrilliantColor

n = 1 (a=30) ~ 10 (a=31 30)

~XX35 1 7E 30 30 33 35 20 31 0D Gamma Film

~XX35 2 7E 30 30 33 35 20 32 0D Video

~XX35 3 7E 30 30 33 35 20 33 0D Graphics

~XX35 4 7E 30 30 33 35 20 34 0D Standard

~XX36 1 7E 30 30 33 36 20 31 0D Color Temp. Warm

~XX36 2 7E 30 30 33 36 20 32 0D Medium

~XX36 3 7E 30 30 33 36 20 33 0D Cold

~XX37 1 7E 30 30 33 37 20 31 0D Color Space Auto

~XX37 2 7E 30 30 33 37 20 32 0D RGB\RGB(0-255)

~XX37 3 7E 30 30 33 37 20 33 0D YUV

~XX37 4 7E 30 30 33 37 20 34 0D RGB(16-235)

~XX73 n 7E 30 30 37 33 20 a 0D Signal Frequency n = -5 (a=2D 35) ~ 5 (a=35) By signal

~XX91 n 7E 30 30 39 31 20 a 0D Automatic n = 0 disable; n = 1 enable

~XX74 n 7E 30 30 37 34 20 a 0D Phase n = 0 (a=30) ~ 31 (a=33 31) By signal

~XX75 n 7E 30 30 37 35 20 a 0D H. Position n = -5 (a=2D 35) ~ 5 (a=35) By timing

~XX76 n 7E 30 30 37 36 20 a 0D V. Position n = -5 (a=2D 35) ~ 5 (a=35) By timing
