General| Matrix size | 0.55 \ |
|---|---|
| Number of colors | 1.073 billion colors |
| Native aspect ratio | 4:3 |
| Projection distance | 1.5 - 11.9 m |
| Projection technology | DLP |
| Supported aspect ratios | 4:3, 5:4, 16:9, 16:10 |
| Contrast ratio (typical) | 4000:1 |
| Screen size compatibility | 40 - 303 \ |
| Projector native resolution | SVGA (800x600) |
| Keystone correction, vertical | ± 40 ° |
| Vertical synchronization (max) | 120 kHz |
| Vertical synchronization (min) | 50 kHz |
| Horizontal synchronization (max) | 100 kHz |
| Horizontal synchronization (min) | 31 kHz |
| Projector brightness (economic mode) | 2200 ANSI lumens |
| Focus | Manual |
| Offset | 15 % |
| Throw ratio | 1.97 - 2.17:1 |
| Zoom capability | Yes |
| Focal length range | - mm |
| Lamp type | UHP |
| Lamp power | 180 W |
| Light source type | Lamp |
| Lamp power (economic mode) | 150 W |
| Service life of light source | 5000 h |
| Service life of light source (economic mode) | 6000 h |
| DVI port | No |
| Audio (L/R) in | - |
| USB connector type | Mini-USB B |
| Serial interface type | RS-232 |
| USB 2.0 ports quantity | USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them. |
| S-Video inputs quantity | 1 |
| VGA (D-Sub) ports quantity | 3 |
| Component video (YPbPr/YCbCr) in | 0 |
| Supported video modes | 1080i, 1080p, 480i, 480p, 576i, 576p, 720p |
| Analog signal format system | NTSC, PAL, SECAM |
| Supported graphics resolutions | 1920 x 1200 (WUXGA) |
| RMS rated power | 2 W |
| Placement | Desktop, Ceiling |
| Product type | Standard throw projector |
| Product color | Black |
| Cable lock slot type | Kensington |
| Power source | AC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 260 W |
| Power consumption (standby) | 1 W |
| Power consumption (typical) | 235 W |
| Noise level | 30 dB |
| Preset modes | Beige wall, Blackboard, Bright, Cinema, Custom, Presentation, Whiteboard |
| Certification | UL, c-UL, FCC, CE |
| Password protection type | User |
| Noise level (economic mode) | 28 dB |
| On Screen Display (OSD) languages | CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, KOR, NOR, POL, POR, RUS, SWE, TUR |
| Operating altitude | 0 - 3048 m |
| Operating temperature (T-T) | 5 - 35 °C |
| Cables included | AC, VGA |
Weight and Dimensions| Depth | 235 mm |
|---|---|
| Width | 284 mm |
| Height | 70 mm |
| Weight | 2170 g |
| Package width | 330 mm |
| Package height | 150 mm |
| Package weight | 3670 g |
Provides warnings and guidelines for safe operation of the projector.
Lists important warnings and precautions for using the projector safely.
Outlines the key capabilities and specifications of the projector.
Details the items included in the projector's box for initial setup.
Provides a general description of the projector's main components.
Identifies and describes the physical parts of the projector's main body.
Explains the buttons and indicators on the projector's physical control panel.
Details the various ports available for connecting external devices to the projector.
Describes the functions and buttons of the infrared remote control.
Guides users on how to connect the projector to a computer or notebook.
Explains how to connect the projector to various external video sources.
Details the steps required to turn the projector on and start operation.
Provides instructions on how to safely shut down and turn off the projector.
Explains the meaning of various LED indicators and warning lights on the projector.
Guides on how to adjust the projector's physical height for optimal image placement.
Explains how to adjust the zoom and focus rings for a clear image.
Details how to change the size of the projected image.
Summarizes the functions of the projector's control panel and remote.
Instructions for installing or replacing batteries in the remote control.
Explains the operation of each button on the remote control.
Guides on how to access and use the projector's built-in help function.
Illustrates how to navigate the help menu for troubleshooting common issues.
Explains how to access and navigate the projector's OSD menus.
Provides a detailed breakdown of the OSD menu structure and options.
Details the specific settings available within SETUP and OPTIONS menus.
Details adjusting display modes, brightness, contrast, and sharpness.
Guides on adjusting color saturation and the red/green balance.
Covers advanced image adjustments like Gamma, BrilliantColor, and Color Temp.
Details fine-tuning color settings and selecting color matrix types.
Explains signal detection, phase, frequency, and position adjustments.
Guides on selecting aspect ratios and understanding auto-format options.
Details image resizing for different aspect ratios in WXGA mode.
Explains Edge Mask, Zoom, Image Shift, and V Keystone adjustments.
Covers 3D mode activation, format selection, and sync inversion.
Details changing OSD language and projector projection orientation.
Details menu location, screen type selection, and projector ID setup.
Covers internal speaker, mute, volume, and audio input configuration.
Explains logo customization and closed captioning features.
Covers enabling/disabling inputs, source lock, and high altitude fan control.
Details IR function control, background color settings, and reset options.
Explains direct power, auto-off timers, quick resume, and power modes.
Covers lamp hours, reminder, brightness modes, and lamp reset.
Details installation, usage hours, reminders, and reset for optional filters.
Guides on resolving issues when no image appears on the screen.
Addresses problems like unstable images, flickering, and notebook presentation issues.
Covers fixing focus, image stretching, size, and slanted sides.
Addresses projector unresponsiveness, blurry images, and 3D display problems.
Explains LED status lights and warning messages for troubleshooting.
Details warning messages and troubleshooting for remote control problems.
Provides safety warnings and essential information before lamp replacement.
Step-by-step guide for safely replacing the projector lamp module.
Instructions for installing and maintaining the projector's dust filter.
Details projector compatibility with various computer and video signals.
Lists compatibility details for different 3D input timings and formats.
Shows the pin configuration for the projector's RS232 serial port.
Details ASCII commands, HEX codes, and functions for RS232 control.
Continues the list of RS232 commands for projector settings and functions.
Continues the list of RS232 commands for projector settings and functions.
Concludes the list of RS232 commands and projector return information.
Provides guidelines and specifications for mounting the projector on a ceiling.
Lists FCC, Canadian, EU notices, and disposal instructions for the projector.
Outlines FCC operation conditions, Canadian notices, EU declarations, and disposal instructions.
