INFOSEC UPS SYSTEM E4 Evolution II + 40k TT HV User Manual

102
INFOSEC UPS SYSTEM – 15, rue du Moulin – 44880 Sautron – France – www.infosec-ups.com
hotline : +33 (0)2 40 76 15 82 – fax : +33(0)2 40 94 29 51 – hotline@infosec.fr – 07 19 AA 59 205 03

HV MODEL (400V)
E4
Evolution
II + 10 k
TT (S)
E4
Evolution
II + 15 k
TT (S)
E4
Evolution
II + 20 k
TT (S)
E4
Evolution
II + 30 k
TT (S)
E4
Evolution
II + 40 k
TT (S)
E4
Evolution
II + 60 k
TT S
E4
Evolution
II + 80 k TT
S
CAPACITY*
10KVA /
10KW
15KVA /
15KW
20KVA /
20KW
30KVA /
30KW
40KVA /
40KW
60KVA /
60KW
80KVA /
80KW
INPUT
Voltage
Range
Low Line Loss
110 VAC(Ph-N) ± 3 % at 50% Load; 176 VAC(Ph-N) ± 3 % at 100% Load
Low Line
Comeback
Low Line Loss Voltage + 10V
High Line Loss
300 VAC(L-N) ± 3 % at 50% Load; 276 VAC(L-N) ± 3 % at 100% Load
High Line
Comeback
High Line Loss Voltage - 10V
Frequency Range
46Hz ~ 54 Hz @ 50Hz system
56Hz ~ 64 Hz @ 60Hz system
Phase
3 Phase with Neutral
Power Factor
≧ 0.99 at 100% Load
OUTPUT
Phase
3 Phase with Neutral
Output voltage
360/380/400/415VAC (Ph-Ph)
208*/220/230/240VAC (Ph-N)
AC Voltage Regulation
± 1%
Frequency Range
(Synchronized Range)
46Hz ~ 54 Hz @ 50Hz system;
56Hz ~ 64 Hz @ 60Hz system
Frequency Range (Batt. Mode)
50 Hz ± 0.1 Hz or 60Hz ± 0.1 Hz
Over
load
AC mode
100%~110%: 60min; 110%~125%: 10min; 125%~150%:1min;>150% : immediately
Battery mode
100%~110%: 60min; 110%~125%: 10min; 125%~150%:1min;>150% : immediately
Current Crest Ratio
3:1 max
Harmonic Distortion
≦ 2 % @ 100% Linear Load; ≦ 5 % @ 100% Non-linear Load
Transfer
Time
Line Battery
0 ms
Inverter
Bypass
0 ms (When phase lock fails, <4ms interruption occurs from inverter to bypass)
Inverter
ECO
<10 ms
EFFICIENCY
AC mode
95.5%
Battery Mode
94.5%
BATTERY
Standard
Model
Type
12 V / 7 Ah
12 V / 9 Ah
12 V / 9 Ah
12 V / 7 Ah
12 V / 9 Ah
N/A
Numbers
20 (10+10)
32 (16+16)
32 (16+16)
(16+16)pcs x 2 strings
Recharge Time
9 hours recover to 90% capacity
Charging Current
(max)
2.0 A ± 10% (Recommended)
1.0~12.0A (Adjustable)
Charging Voltage
+/-136.5
VDC ± 1%
+/-218 VDC ± 1%
Long-run
Model
Type
Depending on applications
Numbers
20
32 ~ 40 (adjustable)
Charging
Current(max.)
1.0~12.0A ±10% (Adjustable)
2.0~24.0A ±10%
(Adjustable)
Charging Voltage
+/-136.5
VDC ± 1%
+/- 13.65 VDC * N ± 1% (N = 16~20)
PHYSICAL
Standard
Model
Dimension, D X W
X H (mm)
626 x 250 x 750
815 x 300 x 1000
N/A
Net Weight (kgs)
124/126
139/141
139/141
225/230
250/260
Long-run
Model
Dimension, D X W
X H mm
626 x 250 x 750
815 x 300 x 1000
790 x 360 x 1010
Net Weight (kgs)
28/30
43/45
43/45
60/65
61/71
108/112
113/117
ENVIRONMENT
Operation Temperature
0 ~ 40°C (the battery life will down when > 25°C)
Operation Humidity
<95 % and non-condensing
Operation Altitude**
<1000m**
