Test/Up +
Mute/Down Button
 Press and hold the two buttons simultaneously more than 1s to enter/exit the
setting menu.
* AC mode means normal mode, CVCF mode means frequency converter mode.


There are 4 LEDs on the front panel to show the UPS working status:
Mode LED
Bypass
Line
Battery
Fault
UPS On
●
●
●
●
No Output mode
○
○
○
○
Bypass mode
●
○
○
○
AC mode
○
●
○
○
Battery mode
○
○
●
○
CVCF mode
○
●
○
○
Battery Test
●
●
●
○
ECO mode
●
●
○
○
Fault
○
○
○
●
Note: ● means LED is ON, and ○ means LED is OFF.











 LCD Panel
 
 

Indicates backup time in numbers when the UPS is in battery mode
H: hours, M: minutes, S: seconds

Indicates that the warning and fault occurs.
Indicates fault codes (listed in details in section 3-8).
 
