14
Parts Listing
Part# Description QTY Part# Description QTY
1 Bottom Tube 2 34 Stopper 1
2
Backrest Support Tube
1 35 EVA Space Pad 1
3 Height Adjustment Tube 1 36 Round End Cap - Ankle Tube 4
4
Footrest
1 37 T-Knob 1
5
Ankle Holding Tube
2 38 Height Adjustment Knob 1
6
Right Handlebar
1 40 Bolt - M8x16mm 2
7
Left Handlebar
1
41 Nylon Snap 4
8L
Rear Base Frame - Left
1 42
Cap Nut M20
1
8R
Rear Base Frame - Right
1 43L Plastic Cover - Left 1
9L
Front Base Frame - Left
1 43R Plastic Cover - Right 1
9R
Front Base Frame - Right
1 44 Spring 1
10
Screw ST2.9x10mm
4
45 Plastic Washer -
￠
20x
￠
9.5x1.2 4
11L Connecting Bracket - Left 1 46 Round End Cap - Handlebars 2
11R
Connecting Bracket - Right
1 47 Backrest 1
12 Cross Bar 1 48 Headrest 1
13 Foam Roller 2 49 Wrench - #13/#17 2
14 Angle Selector Pin -
￠
13.8x88mm 1 50 Hex Wrenches 1
15
Adjustable Ankle Holding Tube
1 51 Bolt - M8x45mm 1
16
Long Pin
1 52 U-Shape Holder 2
17 Spacer - Base Frame 4 53 Plastic U-Shape Cover 2
18
Round End Cap - Base Frame
2 54 Metal Support Plate - 100x38x2.5mm 2
19
Flat Washer -
￠
16x
￠
8.5x1.5
19 55
Square End Cap - Footrest 1
20 Bolt - M8x55mm 10 56
Metal Bushing - 8x8mm 1
21 Lock Nut - M8 17 57 Flat Washer -
￠
22x
￠
8.5x1.5
6
22 Bolt - M8x50mm 1
58
Axis M10 x 52mm 1
23 Bolt - M8x30mm 4
59
Protective Cover 1
24 Square End Cap - Backrest Tube 5
60
Side Shield for Cover
1
25L
Left Handlebar Grip
1
61 Screw - M5x10mm 4
25R
Right Handlebar Grip
1
62 Screw - M4x16mm 3
26
Safety Pin -
￠
8x64mm
1
63 Front Shield For Cover 1
27
Bolt - M8x60mm
2
64 Lumbar Pad 1
28
Hexagonal Bolt - M8x20mm
2
65 Buckle-Male 1
29 Bolt - M8x20mm 4
66 Buckle-Female 1
30 Oval End Caps - Footrest Plate 2
67
Nut M10 2
31 Base Frame End Cap 4
68
Flat Washer ø20xø10.5x1.5 2
32 Hexagonal Bolt - M8x65mm 4
69
Plastic Bushing ø22 2
33 Square End Cap 2
70 Bolt-M8x40mm 1
To Next Page
