‑16‑
Item Specifications
Serial communication 1 x RS485 and 1 x RS232
CAN communication ‑
High‑speed input Single‑phase: 8‑channel 200 k
High‑speed output 4‑axis 200 k, PWM pulse width modulation supported
Extension module Supports up to 8 local extension modules
Extension card ‑
Program language LD, SFC, FB/FC function (LD) supported
Type‑C Supports upload and download of user programs and
firmware upgrade.
IP rating IP20
Dimensions (W x H x D) 24 mm x 100 mm x 83 mm
Weight About 135 g
1.3.2 Power Supply Specifications
Item Specifications
Rated voltage of terminal
input power supply
24 VDC±10% (21.6 VDC to 26.4 VDC)
Rated current of terminal
input power supply
1 A (maximum value at 24 V)
24 V input power supply
protection
Providing protection against short circuit and reverse
connection
Hot‑plugging Not supported
1.3.3 Input Specifications
Item Specifications
Input type Digital input
Number of input channels 8
Input mode SINK/SOURCE
Input voltage class 24 VDC±10% (21.6 VDC to 26.4 VDC)
