Inovance Easy 301 User Manual

‑18‑
Item Specifications
High‑speed
output
(Y0 to Y3)
Output load (resistive
load)
0.5 A/point; 2 A/8‑point
Output load (inductive
load)
7.2 W/point; 24 W/8‑point
Output load (lamp load) 5 W/point, 18 W/8‑point
Hardware response
time ON/OFF
< 1 μs (OFF→ON); < 2 μs (ON→OFF)
Load current
requirements
Load current ≥ 12 mA when used with outputs
greater than 10 kHz
Max. output frequency
200 kHz for resistive load; 0.5 Hz for inductive load;
10 Hz for lamp load
Common
output
(Y4 to Y7)
Output load (resistive
load)
0.5 A/point, 1 A/common terminal
Output load (inductive
load)
6 W/24 VDC (total)
Output load (lamp load) 1 W/24 VDC (total)
Hardware response
time ON/OFF
< 100 μs (OFF→ON, ON→OFF)
Load current
requirements
≥5 mA
Maximum output
frequency
100 Hz with resistive load, 0.5 Hz with inductive
load, 10 Hz with lamp load
PWM output (Y0 to Y3) Maximum frequency 200 kHz, minimum pulse width
2.5 μs, minimum resolution 2.5 μs, adjustable duty
cycle
[1]
0.01% to 99.99%
Leakage current at OFF Less than 30 μA at 24 V
Max. residual voltage during ON Less than 0.5 VDC
Isolation mode Opto‑coupler isolation
Common terminal mode 8‑point/common terminal (polarity of output power
supply being “‑”)
