1. Product Information
- 20 -
1
1.5 De-rating
The drive can be operated at above rated ambient temperature, altitude and default carrier frequency by
de-rating drive capacity.
Ƶ
Carrier Frequency De-rating
When carrier frequency of the drive is increased above default setting, you need to de-rate rated
drive output current according to the following table:
Power Carrier Frequency
Phd (kW) 3 kHz 4 kHz 5 kHz 6 kHz 7 kHz 8 kHz
18.5 100.0% 100.0% 100.0% 100.0% 95.7% 91.6%
22 100.0% 100.0% 100.0% 100.0% 95.5% 91.4%
30 100.0% 100.0% 100.0% 100.0% 93.5% 87.7%
37 100.0% 100.0% 100.0% 94.4% 89.0% 84.0%
45 100.0% 100.0% 100.0% 94.0% 88.6% 83.7%
55 100.0% 100.0% 94.1% 88.9% 84.0% 79.5%
75 100.0% 91.8% 84.2% 77.5% - -
90 100.0% 90.8% 82.3% 74.9% - -
110 100.0% 91.9% 84.4% 77.7% - -
132 100.0% 93.1% 86.7% 80.8% - -
160 100.0% 92.6% 85.7% 79.7% - -
200 100.0% 90.0% 81.0% 73.1% - -
220 100.0% 90.8% 82.5% 75.1% - -
250 100.0% 91.2% 83.2% 76.2% - -
280 100.0% 91.8% 84.3% 77.8% - -
315 100.0% 91.7% 83.9% 77.0% - -
355 100.0% 92.3% 85.2% 78.7% - -
400 100.0% 91.4% 83.6% 76.8% - -
Ƶ
Ambient Temperature De-rating
Drive operation between -10°C to 40°C is normal without de-rating. Operation between 40°C and
50°C requires output current de-rating. Rated output current must be de-rated for 1.5% per 1°C
temperature rise. Permissible maximum temperature is 50°C.
Ƶ
Altitude De-rating
The drive must be de-rated for an installation altitude of above 1000 meters because cooling
effect available from ambient air reduces. Rated output current must be de-rated for 1% per 100
meters. Maximum altitude is 3000 meters.
