12
NS-CF30SS9
www.insigniaproducts.com
9 Remove the two screws holding the bottom hinge on the refrigerator and
remove the hinge.
10 Remove the baffle block from the bottom-right side of the door.
Reinstalling the doors
1 Install the baffle block on the bottom-left side of the door.
2 Install the leveling foot you removed from the left side into the right-bottom
of your refrigerator and install the leveling foot you removed from the right
side into the left bottom.
3 Align the hole in the bottom left of the refrigerator door with the bottom
hinge pin and install the door on the hinge pin.
4 Install the bottom hinge on the left bottom of your refrigerator using the
screws you previously removed. Tighten the screws.
