Insignia NS-CF43SS9 User Manual

12
NS-CF43SS9
www.insigniaproducts.com
9 Remove the two screws holding the bottom hinge on the refrigerator and remove
the hinge.
10 Remove the baffle block from the bottom-left side of the door.
Reinstalling the doors
1 Install the baffle block on the bottom-right side of the door.
2 Install the bottom hinge on the left bottom of your refrigerator using the screws you
previously removed. Tighten the screws.
3 Reinstall the left leveling foot into the right side and the right leveling foot into the
left side.
4 Align the hole in the bottom right of the refrigerator door with the bottom hinge pin,
then install the door on the hinge pin.
Bottom hinge
Screws (2)
Leveling feet
Baffle block
Bottom hinge
Screws (2)
Leveling feet
Refrigerator door
Baffle block

Insignia NS-CF43SS9 Specifications

General

Brand	Insignia
Model	NS-CF43SS9
Category	Refrigerator
Language	English
