Intel D101GGC User Manual

Desktop Board Features
11
Desktop Board Components
Figure 1 shows the approximate location of the major components on desktop board D101GGC.
OM18207
BA
Q OP
D
E
C
Line In
H
DIMM 0
DIMM 1
I
J
F
G
T
V
U
R
S
M L KN
W
Figure 1. Intel Desktop Board D101GGC Components

Intel D101GGC Specifications

General

Form Factor	Micro ATX
Chipset	ATI Radeon Xpress 200
Socket	LGA 775
Memory Type	DDR
Memory Slots	4
Expansion Slots	1 x PCIe x16, 2 x PCI
Storage Interface	SATA
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Audio	6-channel
