安装和更换台式机主板组件
设置 BIOS 配置跳线
注释
更改跳线之前，必须先关闭计算机电源，并从计算机上拔下电源电缆。若在计算机处于通电状态下
拆除跳线，可能会导致计算机运行不稳定。
图 15 显示了本台式机主板上 BIOS 配置跳线块的位置。
图 15. BIOS 配置跳线块
此三针 BIOS 跳线块可用于设置主板的操作模式。表 15 列出了每个可用模式的跳线设置。
41
