Intel Desktop Board DH55PJ Technical Product Specification
50
Table 26. BIOS Setup Configuration Jumper Settings
Function/Mode Jumper Setting Configuration
Normal 1-2
The BIOS uses current configuration information and
passwords for booting.
Configure 2-3
After the POST runs, Setup runs automatically. The
maintenance menu is displayed.
Note that this Configure mode is the only way to clear the
BIOS/CMOS settings. Press F9 (restore defaults) while in
Configure mode to restore the BIOS/CMOS settings to their
default values.
Recovery None
The BIOS attempts to recover the BIOS configuration. A
recovery CD or USB flash drive is required.

Intel DH55PJ Specifications

General

Form Factor	Micro ATX
Socket	LGA 1156
Memory Type	DDR3
Maximum Memory	8 GB
Memory Slots	2
PCI Express x16	1
PCI Express x1	2
PCI Slots	1
Chipset	Intel H55 Express
USB Ports	12
Video Outputs	VGA
SATA Ports	6
