Intellian T130 User Manual

13
INSTALLING THE ANTENNA
Installation Kit
Contains the items required for securing the antenna unit and ACU to your
vessel.
Figure 4. Installation Kit Components
ACU Q’ty Description Size Remark
5
Self-Tapping
Screw
ø 4 x 16
Table Mount
Bracket
10
Flat Head Screw M3 x 8L
Rack Mount
Bracket ACU
5
Sems Bolt M3 x 12L
Table Mount
Bracket ACU
Antenna Q’ty Description Size Remark
5
Hex. Bolt M12 x 80L
Antenna-Deck
5
Flat Washer M12
5
Spring Washer M12
10
Hex. Nut M12
