Interlogix RF-DD1012-K4 Installation Manual

6 / 32 P/N 466-2655 (ML) • REV A • ISS 17MAR16
Specifications
Model
RF-EV1012-K4
RF-EV1012PI-K4
RF-EV1016-K4
RF4012I4
RF4012I4PI
RF4016I4
TX-2213-03-1
TX-2311-03-1
TX-2214-03-1
Detection technology
PIR (9 curtains, view angle 86°)
Detection modes (selectable
by J1)
Standard 3D, bi-curtain*
Target speed range
30 cm/s to 3 m/s
Detectable range (selectable
by J2)
6 and 12 m
6 and
12 m
10 and
16 m
6 and 12 m
6 and
12 m
10 and
16 m
6 and 12 m
6 and
12 m
10 and
16 m
Blinders equipped
Segmented
Full
Segmented
Segmented
Full
Segmented
Segmented
Full
Segmented
Pet immune:
No
Yes
No
No
Yes
No
No
Yes
No
Mounting height
1.8 to 3.0 m
2.3 to
3.0 m
2.3 to 3.0 m
1.8 to 3.0 m
2.3 to
3.0 m
2.3 to 3.0 m
1.8 to 3.0 m
2.3 to
3.0 m
2.3 to 3.0 m
Operating frequency
433.65 MHz
433.92 MHz
868.30 MHz
Power output
<10 dBm
<10 dBm
<10 dBm
Protocol
433-80plus
433-63bit
GEN2
RF range (open air /
obstructed), typical
300 m / 40 m
300 m / 40 m
600 m / 40 m
Detector start-up time
1 min
Supervisory interval
18 min
Lockout timer
3 min
Battery type
3.0 V, 1300 mAh lithium
Battery life (typical with
1 battery)
5 years
Battery included
1X CR123
Current consumption
22 µA (avg.), 50 mA (max.)
Operating temperature
EN −10 to +55°C
Relative humidity
95% max. noncondensing
IP/IK rating
IP30 IK02
Dimensions (LxWxH)
130 x 69 x 53 mm
Weight (incl. 1 battery)
146 g
* Bi-curtain is not tested for EN 50131-2-2.

Interlogix RF-DD1012-K4 Specifications

General

Brand	Interlogix
Model	RF-DD1012-K4
Category	Security Sensors
Language	English
