Detailed Function Description
84
Figure 6.23 FDT Level diagram.
Function
Code
Name Description
Setting
Range
Factory
Setting
P8.27
Frequency arrive
detecting range
0.0~100.0%
(maximum
frequency)
0.0~100.0 0.0%
When output frequency is within the detecting range of reference frequency, an ON-OFF
signal will be output.
Figure 6.24 Frequency arriving detection diagram.
