Wiring
18
4.2 Terminal Configuration
4.2.1 Main Circuit Terminals (380VAC)
R S T U V W
(+) PB (-)
POWER MOTOR
Figure 4.2 Main circuit terminals (1.5~5.5kW).
R S T U V W
(+) PB (-)
POWER MOTOR
Figure 4.3 Main circuit terminals (7.5~15kW).
R S T U V W
POWER
P1 (+) (-)
MOTOR
Figure 4.4 Main circuit terminals (18.5~110kW).
R S T U V W
POWER MOTOR
P1 (+) (-)
Figure 4.5 Main circuit terminals (132~315kW).
R S T U V W
POWER
MOTOR
(resistor)
P1 (+) (-)
Figure 4.6 Main circuit terminals (350~630kW).
