INVT CHV100-2R2G-4 User Manual

Wiring
21
4.4 Specifications of Breaker, Cable, Contactor and Reactor
4.4.1 Specifications of breaker, cable and contactor
Model No.
Circuit
breaker (A)
Input/output cable (mm
2
)
(Coppery wire)
Rated current of
contactor (A)
(380V or 220V)
3AC 220V ±15%
CHV100-0R7G-2 16 2.5 10
CHV100-1R5G-2 20 4 16
CHV100-2R2G-2 32 6 20
CHV100-004G-2 40 6 25
CHV100-5R5G-2 63 6 32
CHV100-7R5G-2 100 10 63
CHV100-011G-2 125 25 95
CHV100-015G-2 160 25 120
CHV100-018G-2 160 25 120
CHV100-022G-2 200 35 170
CHV100-030G-2 200 35 170
CHV100-037G-2 200 35 170
CHV100-045G-2 250 70 230
3AC 380V ±15%
CHV100-1R5G-4 16 2.5 10
CHV100-2R2G-4 16 2.5 10
CHV100-004G-4 25 4 16
CHV100-5R5G-4 25 4 16
CHV100-7R5G-4 40 6 25
CHV100-011G-4 63 6 32
CHV100-015G-4 63 6 50
CHV100-018G-4 100 10 63
CHV100-022G-4 100 16 80
CHV100-030G-4 125 25 95
CHV100-037G-4 160 25 120
CHV100-045G-4 200 35 135
CHV100-055G-4 200 35 170
CHV100-075G-4 250 70 230
CHV100-090G-4 315 70 280
CHV100-110G-4 400 95 315
CHV100-132G-4 400 150 380
CHV100-160G-4 630 185 450
CHV100-185G-4 630 185 500
CHV100-200G-4 630 240 580
CHV100-220G-4 800 150x2 630
CHV100-250G-4 800 150x2 700
CHV100-280G-4 1000 185x2 780
CHV100-315G-4 1200 240x2 900
